Fujitsu M10 User Manual

Table 2-3
Third-party rack checklist
Description Condition Letter in
figure
Rack type/Compliance
standards
Equipment rack/EIA standard-compliant --
Dimension between rear door
(inside) and front column
SPARC M10-1: At least 917 mm (36.1 in.)
SPARC M10-4: At least 844 mm (33.2 in.)
SPARC M10-4S: At least 930 mm (36.6 in.)
PCI-BOX: At least 848 mm (33.4 in.)
A
Dimension between front door
(inside) and front column
SPARC M10-1: At
least 40 mm (1.5 in.)
SPARC M10-4: At least 32 mm (1.3 in.)
SPARC M10-4S: At least 32 mm (1.3 in.)
PCI-BOX: At least 24 mm (0.9 in.)
B
Dimension between front and
rear columns
Within adjustment range of rack mount kit
Adjustment range of the mount kit for each server
SPARC M10-1:
612 mm
(24.1 in.) to 925 mm (36.4 in.)
SPARC M10-4:
630 mm (24.8 in.) to 840 mm (33.1 in.)
SPARC M10-4S:
630 mm (24.8 in.) to 840 mm (33.1 in.)
PCI-BOX:
630 mm (24.8 in.) to 840 mm (33.1 in.)
C
Dimension between rear door
(inside) and rear column
SPARC M10-1: No conditions
SPARC M10-4: At
least 158 mm (6.2 in.)
SPARC M10-4S: At least 158 mm (6.2 in.)
PCI-BOX: At least 158 mm (6.2 in.)
D
Front panel mounting space of
chassis
At least 483 mm (19.0 in.) E
Distance between left and right
chassis attachment holes
(common to front and rear
columns)
465 mm (18.3 in.) F
Distance between left and right
columns
(common to front and
rear columns)
At least 450 mm (17.7 in.) G
Column thickness 2 mm (0.08 in.) to 2.5 mm (0.1 in.) H
Structures other than columns Rack has no structures between front and rear
columns
I
Cable hatch Rack has hatch on bottom surface, rear door, or
elsewhere
J
Area of door vent openings Front door: At
least 73 % of door area
Rear door: At least 73 % of door area
K
Chapter 2 Planning and Preparing for System Installation 25
