Table 2-3
Third-party rack checklist (continued)
Description Condition L ette r in
figure
Size of chassis attachment
holes (common to front and
rear columns)
SPARC M10-1:
Square hole with sides longer than 9 mm (0.35 in.)
and not longer than 9.8 mm (0.38 in.) or M6 screw
hole
SPARC M10-4/SPARC M10-4S/PCI-BOX:
Square hole with sides longer than 9.2 mm (0.36
in.) and not longer than 9.8 mm
(0.38 in.) (*1) or
M6 screw hole
L
Vertical pitch of chassis
attachment holes
(common to front and rear
columns)
EIA standards, universal pitch M
Door opening angle Door opens to 130° --
Strength Rack has necessary strength/load capacity for
mounting chassis
--
Grounding Rack and units can be grounded --
Toppling prevention measures Rack can be prevented from toppling over --
Earthquake resistance measures Earthquake resistance measures can be
implemented for rack
--
*1 If the SPARC M10-4, M10-4S, or PCI expansion unit has square holes with sides of 9.0 mm (0.35 in.) to 9.2 mm
(0.36 in.), a separate rack mount kit must be ordered.
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 201526
