FRONT
PDU#0 or PDU#2 (*1)
PDU#1 or PDU#3(*1)
*1 PDU#0 and PDU#1 are for expansion rack 1. PDU#2 and PDU#3 are for expansion rack 2.
c. Connect the power cords to the PDUs.
Each cable has an attached label showing the connection destination. Each
PDU also has an indicator. So, match it with the right cable to connect the
cable. For the PDU mounting locations, see Figure 3-12.
Figure 3-12
Connecting power cords
Chapter 3 Installing the System 85
