RX300 S3 Operating manual 9
Introduction Features
Further sources of information
– technical manual for the rack
– manual for the monitor
– server management manual ServerView
– manual for the Remote Test and Diagnostic System RemoteView
– in the documentation for the boards and drives
– operating system documentation
– information files of your operating system
(see also “Related Publications” on page 103).
1.2 Features
System board
The features of the system board (D2119 are described in the technical manual
for the system board in relation to the hardware and in the BIOS setup manual
(see “Related Publications” on page 103).
Slots for additional boards
There are up to fife extension slots for additional controller boards on the system
board of the server:
Figure 1: PCI slots: basic configuration
LAN 1 LAN 2
+
