197
PRIMERGY TX150 S4 User’s Guide
Installing hardware options
7
■ Installing the Remote Service Board
●
Notes Before Installing
When installing the remote service board, note the following points:
` To use the remote service board, ServerView is required. Be sure to install it. For how to install
ServerView, refer to "6.2 Server Monitoring Tool [ServerView]" (Jpg.178). For the remote service
board functions, refer to "ServerView User's Guide."
` When the remote service board is connected, the monitor brightness may become lower. In this case,
adjust the monitor for higher brightness.
` The recommended screen refresh rate for the monitor is 70Hz. In case of poor resolution of the
monitor display, set the screen refresh rate to 70Hz.
● Connecting the Server Control Cable
When installing the remote service board, the server control cable needs to be connected.
Connect the server control cable that came with the remote service board as shown in the figure below.
Connect one end to the connector on the remote service board and the other end to the connector on the
baseboard. Then install the remote service board in PCI Slot 1.
• Do not connect the remote service board AC adapter until you finish installing
the remote service board and attaching all the server covers. Doing so may
cause a device failure, fire, or electric shock.
• When replacing remote service boards or adding other optional devices,
unplug the power cable of the remote service board AC adapter from the outlet
before operation. Failure to do so may cause a device failure, fire, or electric
shock.
To Next Page
