44
4 Technical threshold values for planning
4.4 Clearance for the basic vehicle and bodies
MITSUBISHI FUSO body/equipment mounting directives for FE Issue date: 20. 10. 2020
! Only print out complete sections from the current version
Battery
Mounting hardware must be located so that battery
removal/installation and inspection as well as battery
cover detaching/attaching can be done easily.
4.4.2 Attachment above cab
• Observe the permissible center of gravity location
and the front axle load.
• Make sure that there is sufficient space for tilting
Refer to "10.4.3 Cab side view" É 10.4.3.
i Additional information
Read and comply with the relevant sections of the
body/equipment mounting directives.
Cab tilting range clearance
