Futurecom VR - Page 102

8G093X01 R5
VR Programming Guide
August 2022 Page 102 of 144
Field Name
Range
Description
Notes
This VR ID ¤
0 to
16777215
(MSU ID)
0 displayed
as ‘MSU ID’
Specifies the ID of
the VR, which is
used for remote VR
mode and TG
change.
If set to ‘MSU ID’ the VR will assume the ID of the
currently interfaced MSU.
Refer to “Remote VR Activation and Steering by
PSU Call Alert (Page)” section in VR Functional
Description document
Block
Fallback to
Local Repeat
Checkbox
(unchecked)
When this box is
checked and the
MSU can’t reach
the system, this
prevents the
DVR/DVR-LX from
repeating locally.
MSU RF
Bypass
Switch
Extension
(APX 8500
and All Band
Antenna)
Checkbox
Bypasses the MSU
filter when a cross
band channel is
selected
Required for inband application for APX8500 w All
Band antenna.
The following configuration is also required:
Hardware Setup → MSU RF Bypass Switch =
checked (enabled)
Refer to DVR-LX Installation Guide for further
information
