Futurecom VR - Page 125

8G093X01 R5
VR Programming Guide
August 2022 Page 125 of 144
Field Name
Range
Description
Notes
Tx RSSI.
Thresh.
Max = -60
Default = -100
Min - -110
Refer to Repeater Channel Setup
Tx RSSI.
Thresh.
Margin
(-6) (3) – (10)
dBm
Sets the margin for the Tx. RSSI Threshold
to cover worst case scenarios due to
varying RF conditions.
Rx RSSI
Thresh.
Max = -60
Default = -100
Min = -110
Refer to Repeater Channel Setup
Rx RSSI
Thresh.
Margin
(-6) (-4) – (10)
dBm
Sets the margin for the Rx. RSSI
Threshold to cover worst case scenarios
due to varying RF conditions.
Set Test Mode
OFF
ON
Sets the VR in auto test mode to carry out
RSSI On Level Test, Busy Lock. Thresh.
Test & Primary Range Test. In Test mode
the VR displays this "Warning 2000" on the
control head.
VR in Test
Mode
Yes
No
Indicates if the VR is currently in a test
mode.
Set Remote
Test Mode
OFF
ON
Sets the secondary VR in auto test mode
to carry out Busy Lock. Thres. Test &
Primary Range Test.
A second VR in
remote (secondary)
mode and local or
systems operating
mode must be
present, it’s ID set as
the 'Remote VR ID',
and 'Set test Mode'
set to ON to set this
field to ON. When set
to ON, both VRs
displays "Warning
2000" alternatively in
the control head.
"Enter Remote Test
Mode - Command
Failed" will be
displayed in the
window if the stated
conditions are not
met.
Remote VR in
Test Mode
Yes
No
Indicates if the remote (secondary) VR is
currently in test mode.
Remote VR ID:
Max =
16777215
Default = 1
Min = 0
Allows the user to provide the ID of the
remote (secondary) VR to connect to for
the Busy Lock. Thresh. Test and Primary
Range Test.
xxx in
progress xxx
sec. to the end
Indicates the current test being run and
how much time remains to complete the
test.
