Allows the user to start an automated RSSI
ON Level Test that sets up the RSSI ON
Threshold levels for the desired coverage
area.
Test involves a primary VR and a remote
PSU located at the boundary of the desired
coverage area.
The remote PSU transmits a known signal
which is received by the Primary VR and
measured to determine RSSI ON
Threshold level.
On completion of the test, a check mark is
placed beside RSSI ON Thresh. and the
value for this field is modified in the
repeater channel setup window.
Allows the user to start an automated test
that sets up the busy lock threshold and
the Tx RSSI threshold levels for the
desired coverage area.
Test involves two VRs located at the
boundary of the desired coverage area and
engaged in Primary Secondary interaction.
The secondary (remote) VR transmits a
known signal which is received by the
Primary VR and measured to determine BL
threshold level.
On completion of the test, a check mark is
placed beside Busy Loc. Thresh and Tx
RSSI Thresh. and the values for these
fields are modified in the repeater channel
setup window.
The test may fail if the levels are outside
the upper and lower limits of BL threshold
and/or Tx RSSI Threshold. If the test fails
for the upper limit, move the secondary VR
away from the primary and if the test fails
for the lower limit, bring the secondary VR
closer to the primary.
