Futurecom VR - Page 89

8G093X01 R5
VR Programming Guide
August 2022 Page 89 of 144
Field Name
Range
Description
Notes
Input
Polarity
Active High
Active Low
Defines the VR ON / OFF trigger
polarity when an external switch is
wired to pin 1 of the DB15
connector on the DVR Auxiliary
cable (7W083X06-01).
Applicable when the VR
ON / OFF activation
trigger is wired to the
DVR Auxiliary cable.
Not applicable when the
VR ON / OFF trigger is
wired to the mobile radio
CH VIP.
If set to Active High,
leaving Pin 1 on the
Auxiliary Cable
disconnected is Active,
and grounding Pin 1 is
Inactive.
If set to Active Low,
grounding Pin 1 on the
Auxiliary Cable is Active
and leaving Pin 1
disconnected is Inactive.
GPS Driven Deactivation
8
GPS
Driven
Deactivati
on
Enable / Disable
Check box
Enables or Disables the GPS
Driven Deactivation feature
Only allowed if license for
feature has been
obtained.
If enabled, a Speed
Threshold and/or a
Distance Threshold must
be specified
Speed
Enable / Disable
Check box
Enables or Disables use of a
speed threshold to
deactivate repeater
Speed
Threshold
5 to 100 (15)
mph
8 to 160 (24)
km/h
Speed threshold used to trigger
VR deactivation
Only applicable if Speed
is enabled.
Value for km/h is
approximate based on
value in mph.
Speed
Units
mph, km/h
Determines whether speed
threshold is expressed in terms of
“miles per hour” or “kilometers
per hour”
Only applicable if Speed
is enabled
Threshold
Logic
Or, And
Determines whether VR
deactivation is driven by reaching
either speed or distance threshold,
or whether both thresholds must
be met to trigger
repeater deactivation
Only applicable if both
Speed and Distance are
enabled.
IF “And” is chosen, then
VR deactivation occurs
when both speed and
distance thresholds are
met.
8
Refer to How-to section below for details on how to program the GPS driven deactivation feature
