Futurecom VR - Page 99

8G093X01 R5
VR Programming Guide
August 2022 Page 99 of 144
Field Name
Range
Description
Notes
Inactivity
Timer
0 to 120 (0)
min
If the VR is not
active (does not
receive any local
PSU calls) for the
programmed
period, it will
automatically
switch from System
or Local to OFF
Mode. The VR
sends warning
tones to alert the
Local PSU users
every minute during
the last 5 minutes
prior to switching
OFF.
Outbound calls, received by the MSU and repeated
by the VR will not reset the timer.
Display
PTT ID
Check box
(checked)
Enables / Disables
the display of
Portable PTT ID on
the Control Head.
TG ID
Check box
(unchecked)
Outbound calls TG
ID is displayed
(when enabled)
during proxied calls
as well.
Hang Time
0-5 (0) sec
Determines the
hang time during
which the ID
remains displayed
after the call has
ended.
Repeater
Active Tones
Check box
(unchecked)
Controls the
sending of tones
when the VR
changes to System
mode. The tones
are transmitted
over the air to all
Local PSUs tuned
to the same VR
conventional
channel.
Tones are sent for the following mode changes:
- OFF to SYS
- LOC to SYS
When Local Mode Active Tones field is enabled,
the tones are sent as outlined for that field instead of
as outlined above.
Refer to
Table 5 - Repeater Active Tones enabled
Local Mode
Active Tones
Check box
(unchecked)
Controls the
sending of tones
when the VR
changes to Local
mode. The tones
are transmitted over
the air to all Local
PSUs tuned to the
same VR
conventional
channel. These
tones will be sent in
addition to the tones
when the VR
changes to System
mode.
Requires enabling of the ‘Repeater Active Tones’
field and now tones will be sent according to the
following mode changes instead:
- OFF to LOC
- OFF to SYS
Additionally, tones will be sent for the following
mode changes for Analog/Mixed VR Channels:
- LOC to SYS
- SYS to LOC
Refer to
Table 6 - Repeater Active Tones & Local Mode
Active Tones enabled
