CHAPTER 2: Checking Out Your Notebook
6
Top
Component Icon Description
Missing pen
indicator
■
LED on and missing pen alarm sounding or LED blinking
- Pen is not in the pen holder while the convertible
notebook is turned off. For more information, see “Pen
alarm” on page 47.
■
LED off - Pen is in place in the pen holder or pen has been
removed while the convertible notebook is turned on.
Battery
charge
indicator
■
LED blue - Battery is fully charged.
■
LED purple - Battery is charging.
■
LED blinking red - Battery charge is very low.
■
LED solid red - Battery is malfunctioning.
Important: This LED only lights up when your notebook is
connected to AC power or the battery charge is very low.
Power
indicator
■
LED on - Notebook is on.
■
LED blinking - Notebook is in Sleep or Hybrid Sleep mode.
■
LED off - Notebook is off.
Battery charge indicator
Power indicator
Missing pen indicator
