Bottom
Component Icon Description
Hard drive
bay
The hard drive is located in this bay. For more
information, see “Replacing the hard drive kit” on
page 112.
Customer
Care label
Includes the Customer Care contact information. For
more information, see “Gateway contact information”
on page 3.
DVD drive Insert CDs or DVDs into this drive. For more
information, see “Using the DVD drive” on page 56. To
determine the type of drive in your notebook,
examine the drive tray’s plastic cover and compare
the logo to those listed in “Identifying drive types” on
page 56.
Battery lock Slide to unlock the battery. For more information, see
“Changing the battery” on page 71.
Battery Provides power when the convertible notebook is not
plugged into AC power.
Battery latch Slide to release the battery. For more information, see
“Changing the battery” on page 71.
Memory bay Install a memory module into this bay. For more
information, see “Adding or replacing memory
modules” on page 109.
Battery
Battery lock
Battery latch
Hard
drive bay
Memory
bay
DVD drive
Customer
care label
