JF-240UV User Manual
43
Step 6. Select LOAD MADIA, and then adjust the height of platen of JF-240 to proper
position.
(Note: the printing side should always be adjusted BELOW the print head.)
Step 7. Select AMC to autamatically detect the height between print media and print
head.
(Note: It is suggested to apply AMC onto the highest position of the media.)
Step 8. Send the file from FlexiPRINT GCC Edition RIP software, and printing is complete.
Example 2: Set parameter settings of SmartPOSITION (define a diagonal as print size)
Please load the rigid material correctly according to following steps.
Step 1. Entre FLATBED mode.
Step 2. Select MENU.
Step 3. Select USER SET.
Step 4. Select USER 1 and select BACK icon .
(Note: Choose USER1/USER2/USER3 to save the settings of SmartPOSITION, so user can print on
the same area without repeatedly setting)
