GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG97
2A72 Digital Input 6 Alarm 0 2 1 - F115 0
2A73 Digital Input 6 Alarm Relays 0 6 1 - F113 0
2A74 Digital Input 6 Alarm Delay 1 50000 1 100ms F2 50
2A75 Digital Input 6 Alarm Events 0 1 1 - F103 0
2A76 Digital Input 6 Trip 0 2 1 - F115 0
2A77 Digital Input 6 Trip Relays 0 6 1 - F111 0
2A78 Digital Input 6 Trip Delay 1 50000 1 100ms F2 50
2A79 Digital Input 6 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 3 – DIGITAL INPUT 3
2A80
1st & 2nd Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
↓↓
2A85
11th & 12th Character of Digital Input 3
Name
32 127 1 - F22 ’GE’
2A90 Digital Input 3 Type 0 1 1 - F116 0
2A91 Reserved
2A92 Digital Input 3 Alarm 0 2 1 - F115 0
2A93 Digital Input 3 Alarm Relays 0 6 1 - F113 0
2A94 Digital Input 3 Alarm Delay 1 50000 1 100ms F2 50
2A95 Digital Input 3 Alarm Events 0 1 1 - F103 0
2A96 Digital Input 3 Trip 0 2 1 - F115 0
2A97 Digital Input 3 Trip Relays 0 6 1 - F111 0
2A98 Digital Input 3 Trip Delay 1 50000 1 100ms F2 50
2A99 Digital Input 3 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 4 – DIGITAL INPUT 2
2AA0
1st & 2nd Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
↓↓
2AA5
11th & 12th Character of Digital Input 2
Name
32 127 1 - F22 ’GE’
2AB0 Digital Input 2 Type 0 1 1 - F116 0
2AB1 Reserved
2AB2 Digital Input 2 Alarm 0 2 1 - F115 0
2AB3 Digital Input 2 Alarm Relays 0 6 1 - F113 0
2AB4 Digital Input 2 Alarm Delay 1 50000 1 100ms F2 50
2AB5 Digital Input 2 Alarm Events 0 1 1 - F103 0
2AB6 Digital Input 2 Trip 0 2 1 - F115 0
2AB7 Digital Input 2 Trip Relays 0 6 1 - F111 0
2AB8 Digital Input 2 Trip Delay 1 50000 1 100ms F2 50
2AB9 Digital Input 2 Assignable Function 0 3 1 - F163 0
... Reserved
RRTD 4 – DIGITAL INPUT 5
2AC0
1st & 2nd Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
↓↓
2AC5
11th & 12th Character of Digital Input 5
Name
32 127 1 - F22 ’GE’
2AD0 Digital Input 5 Type 0 1 1 - F116 0
2AD1 Reserved
2AD2 Digital Input 5 Alarm 0 2 1 - F115 0
2AD3 Digital Input 5 Alarm Relays 0 6 1 - F113 0
2AD4 Digital Input 5 Alarm Delay 1 50000 1 100ms F2 50
2AD5 Digital Input 5 Alarm Events 0 1 1 - F103 0
2AD6 Digital Input 5 Trip 0 2 1 - F115 0
2AD7 Digital Input 5 Trip Relays 0 6 1 - F111 0
2AD8 Digital Input 5 Trip Delay 1 50000 1 100ms F2 50
2AD9 Digital Input 5 Assignable Function 0 3 1 - F163 0
... Reserved
Table CG–10: MEMORY MAP (Sheet 52 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
