GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG83
2424 RRTD 3 - RTD #2 Alarm 0 2 1 - F115 0
2425 RRTD 3 - RTD #2 Alarm Relays 0 7 1 - F113 1
2426 RRTD 3 - RTD #2 Alarm Level 1 200 1 °C F1 130
2427 Record RRTD 3 - RTD #2 Alarms as Events 0 1 1 - F103 0
2428 RRTD 3 - RTD #2 Trip 0 2 1 - F115 0
2429 Enable RRTD 3 - RTD #2 Trip Voting 0 13 1 - F122 1
242A RRTD 3 - RTD #2 Trip Relays 0 7 1 - F111 1
242B RRTD 3 - RTD #2 Trip Level 1 200 1 °C F1 130
242C RRTD 3 - RTD #2 RTD Type 0 3 1 - F120 0
2430 First Character of RRTD 3 - RTD #2 Name 32 127 1 - F1 ’R’
↓↓
2433 8th Character of RRTD 3 - RTD #2 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #3
2440 RRTD 3 - RTD #3 Application 0 4 1 - F121 0
2441 RRTD 3 - RTD #3 High Alarm 0 2 1 - F115 0
2442 RRTD 3 - RTD #3 High Alarm Relays 0 7 1 - F113 2
2443 RRTD 3 - RTD #3 High Alarm Level 1 200 1 °C F1 130
2444 RRTD 3 - RTD #3 Alarm 0 2 1 - F115 0
2445 RRTD 3 - RTD #3 Alarm Relays 0 7 1 - F113 1
2446 RRTD 3 - RTD #3 Alarm Level 1 200 1 °C F1 130
2447 Record RRTD 3 - RTD #3 Alarms as Events 0 1 1 - F103 0
2448 RRTD 3 - RTD #3 Trip 0 2 1 - F115 0
2449 Enable RRTD 3 - RTD #3 Trip Voting 0 13 1 - F122 1
244A RRTD 3 - RTD #3 Trip Relays 0 7 1 - F111 1
244B RRTD 3 - RTD #3 Trip Level 1 200 1 °C F1 130
244C RRTD 3 - RTD #3 RTD Type 0 3 1 - F120 0
2450 First Character of RRTD 3 - RTD # Name 32 127 1 - F1 ’R’
↓↓
2453 8th Character of RRTD 3 - RTD #3 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #4
2460 RRTD 3 - RTD #4 Application 0 4 1 - F121 0
2461 RRTD 3 - RTD #4 High Alarm 0 2 1 - F115 0
2462 RRTD 3 - RTD #4 High Alarm Relays 0 7 1 - F113 2
2463 RRTD 3 - RTD #4 High Alarm Level 1 200 1 °C F1 130
2464 RRTD 3 - RTD #4 Alarm 0 2 1 - F115 0
2465 RRTD 3 - RTD #4 Alarm Relays 0 7 1 - F113 1
2466 RRTD 3 - RTD #4 Alarm Level 1 200 1 °C F1 130
2467 Record RRTD 3 - RTD #4 Alarms as Events 0 1 1 - F103 0
2468 RRTD 3 - RTD #4 Trip 0 2 1 - F115 0
2469 Enable RRTD 3 - RTD #4 Trip Voting 0 13 1 - F122 1
246A RRTD 3 - RTD #4 Trip Relays 0 7 1 - F111 1
246B RRTD 3 - RTD #4 Trip Level 1 200 1 °C F1 130
246C RRTD 3 - RTD #4 RTD Type 0 3 1 - F120 0
2470 First Character of RRTD 3 - RTD #4 Name 32 127 1 - F1 ’R’
↓↓
2473 8th Character of RRTD 3 - RTD #4 Name 32 127 1 - F1 " "
... Reserved
RRTD 3 – RTD #5
2480 RRTD 3 - RTD #5 Application 0 4 1 - F121 0
2481 RRTD 3 - RTD #5 High Alarm 0 2 1 - F115 0
2482 RRTD 3 - RTD #5 High Alarm Relays 0 7 1 - F113 2
2483 RRTD 3 - RTD #5 High Alarm Level 1 200 1 °C F1 130
2484 RRTD 3 - RTD #5 Alarm 0 2 1 - F115 0
2485 RRTD 3 - RTD #5 Alarm Relays 0 7 1 - F113 1
2486 RRTD 3 - RTD #5 Alarm Level 1 200 1 °C F1 130
2487 Record RRTD 3 - RTD #5 Alarms as Events 0 1 1 - F103 0
2488 RRTD 3 - RTD #5 Trip 0 2 1 - F115 0
Table CG–10: MEMORY MAP (Sheet 38 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
