CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG103
6.8 Format Codes
Table CG–11: Memory Map Data Formats (Sheet 1 of 27)
CODE TYPE DEFINITION
F1 16 bits
UNSIGNED VALUE
Example: 1234 stored as 1234
F2 16 bits
UNSIGNED VALUE, 1 DECIMAL PLACE
Example: 123.4 stored as 1234
F3 16 bits
UNSIGNED VALUE, 2 DECIMAL PLACES
Example: 12.34 stored as 1234
F4 16 bits
2’s COMPLEMENT SIGNED VALUE
Example: -1234 stored as -1234 (i.e. 64302)
F5 16 bits
2’s COMPLEMENT SIGNED VALUE, 1 DECIMAL PLACES
Example: -123.4 stored as -1234 (i.e. 64302)
F6 16 bits
2’s COMPLEMENT SIGNED VALUE, 2 DECIMAL PLACES
Example: -12.34 stored as -1234 (i.e. 64302)
F7 16 bits
2’s COMPLEMENT SIGNED VALUE, 3 DECIMAL PLACES
Example: -1.234 stored as -1234 (i.e. 64302)
F8 16 bits
2’s COMPLEMENT SIGNED VALUE, 4 DECIMAL PLACES
Example: -0.1234 stored as -1234 (i.e. 64302)
F13
16 bits INSTALLED OPTIONS
xxxx xxxx xxxx xxx1 Profibus-DP (0 = Not Installed, 1 = Installed)
xxxx xxxx xxxx xx1x Fiber Optic (0 = Not Installed, 1 = Installed)
xxxx xxxx xxxx x1xx Metering (0 = Not Installed, 1 = Installed)
xxxx xxxx xxxx 1xxx Backspin (0 = Not Installed, 1 = Installed)
xxxx xxxx xxx1 xxxx Local RTD (0 = Not Installed, 1 = Installed)
xxxx xxxx xx1x xxxx Power Supply Type (0 = LO, 1 = HI)
xxxx xxxx 1xxx xxxx Modbus/TCP (0 = Not Installed, 1 = Installed)
xxxx xxx1 xxxx xxxx DeviceNet (0 = Not Installed, 1 = Installed)
xxxx xx1x xxxx xxxx Harsh Environment (0 = Not Installed, 1 = Installed)
xxxx x1xx xxxx xxxx Profibus-DPV1 (0 = Not Installed, 1 = Installed)
xxxx 1xxx xxxx xxxx Enhanced Diagnostics (0 = Not Installed, 1 = Installed)
F15
16 bits HARDWARE REVISION
0000 0000 0000 0001 1 = A
0000 0000 0000 0010 2 = B
0000 0000 0000 0011 3 = C
0000 0000 0001 1010 26 = Z
F16
16 bits SOFTWARE REVISION
1111 1111 xxxx xxxx Major Revision Number, 0 to 9 in steps of 1
xxxx xxxx 1111 1111
Minor Revision Number (two BCD digits), 00 to 99 in steps of 1
Example: Revision 2.30 stored as 0230 hex
