GE 369

CG66 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
1784 Enable Prediction Algorithm 0 1 1 - F103 1
1785 Assign Backspin Inhibit Relays 0 7 1 - F111 1
1786 Number of Motor Poles 2 16 2 - F1 2
... Reserved
LOCAL RTD #1
1790 Local RTD #1 Application 0 4 1 - F121 0
1791 Local RTD #1 High Alarm 0 2 1 - F115 0
1792 Local RTD #1 High Alarm Relays 0 7 1 - F113 2
1793 Local RTD #1 High Alarm Level 1 200 1 °C F1 130
1794 Local RTD #1 Alarm 0 2 1 - F115 0
1795 Local RTD #1 Alarm Relays 0 7 1 - F113 1
1796 Local RTD #1 Alarm Level 1 200 1 °C F1 130
1797 Record RTD #1 Alarms as Events 0 1 1 - F103 0
1798 Local RTD #1 Trip 0 2 1 - F115 0
1799 Enable RTD #1 Trip Voting 0 13 1 - F122 1
179A Local RTD #1 Trip Relays 0 7 1 - F111 1
179B Local RTD #1 Trip Level 1 200 1 °C F1 130
179C Local RTD #1 RTD Type 0 3 1 - F120 0
17A0 First Character of Local RTD #1 Name 32 127 1 - F1 ’R’
↓↓ --- - - -
17A3 8th Character of Local RTD #1 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #2
17B0 Local RTD #2 Application 0 4 1 - F121 0
17B1 Local RTD #2 High Alarm 0 2 1 - F115 0
17B2 Local RTD #2 High Alarm Relays 0 7 1 - F113 2
17B3 Local RTD #2 High Alarm Level 1 200 1 °C F1 130
17B4 Local RTD #2 Alarm 0 2 1 - F115 0
17B5 Local RTD #2 Alarm Relays 0 7 1 - F113 1
17B6 Local RTD #2 Alarm Level 1 200 1 °C F1 130
17B7 Record RTD #2 Alarms as Events 0 1 1 - F103 0
17B8 Local RTD #2 Trip 0 2 1 - F 115 0
17B9 Enable RTD #2 Trip Voting 0 13 1 - F122 1
17BA Local RTD #2 Trip Relays 0 7 1 - F111 1
17BB Local RTD #2 Trip Level 1 200 1 °C F1 130
17BC Local RTD #2 RTD Type 0 3 1 - F120 0
17C0 First Character of Local RTD #2 Name 32 127 1 - F1 ’R’
↓↓
17C3 8th Character of Local RTD #2 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #3
17D0 Local RTD #3 Application 0 4 1 - F121 0
17D1 Local RTD #3 High Alarm 0 2 1 - F115 0
17D2 Local RTD #3 High Alarm Relays 0 7 1 - F113 2
17D3 Local RTD #3 High Alarm Level 1 200 1 °C F1 130
17D4 Local RTD #3 Alarm 0 2 1 - F115 0
17D5 Local RTD #3 Alarm Relays 0 7 1 - F113 1
17D6 Local RTD #3 Alarm Level 1 200 1 °C F1 130
17D7 Record RTD #3 Alarms as Events 0 1 1 - F103 0
17D8 Local RTD #3 Trip 0 2 1 - F115 0
17D9 Enable RTD #3 Trip Voting 0 13 1 - F122 1
17DA Local RTD #3 Trip Relays 0 7 1 - F111 1
17DB Local RTD #3 Trip Level 1 200 1 °C F1 130
17DC Local RTD #3 RTD Type 0 3 1 - F120 0
17E0 First Character of Local RTD #3 Name 32 127 1 - F1 ’R’
↓↓
17E3 8th Character of Local RTD #3 Name 32 127 1 - F1 " "
... Reserved
Table CG–10: MEMORY MAP (Sheet 21 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
