GE 369

CGCOMMUNICATIONS GUIDE DEVICENET PROTOCOL
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG35
4.13 DeviceNet Data Formats
201, 202 (low, high) Starts timer [2] 16 bits UINT minutes
203, 204 (low, high) Starts timer [3] 16 bits UINT minutes
205, 206 (low, high) Starts timer [4] 16 bits UINT minutes
207, 208 (low, high) Starts timer [5] 16 bits UINT minutes
209, 210 (low, high) Time between starts timer 16 bits UINT minutes
211, 212 (low, high) Restart block timer 16 bits UINT seconds
213, 214 (low, high) Start inhibit timer 16 bits UINT minutes
DATA FORMATS FOR CLASS CODE B0H, INSTANCE 1 (Sheet 6 of 6)
ATTRIBUTE BYTES DESCRIPTION LENGTH FORMAT VALUE/UNIT
FORMAT VALUE NAME/DESCRIPTION
F167 Network status: unsigned 16 bit integer
0 Power off / Not online
1 Online, Connected
2 Link failure
3Not defined
F168 Connection status: unsigned 16 bit integer
0Nonexistent
1Configuring
2(Not used)
3 Established
4Timed out
5Deferred delete
F170 DeviceNet baud rate: unsigned 16 bit integer
0 125 kbps
1 250 kbps
2 500 kbps
F172 Motor status: Unsigned 8 bit integer
Bit 0 Stopped
Bit 1 Starting
Bit 2 Running
Bit 3 Overloaded
Bit 4 Tripped
Bits 5 to 7 Reserved
F173 Digital input status: unsigned 8 bit integer
Bit 0
Access Switch Status
0 = Open, 1= Closed
Bit 1
Speed Switch Status
0 = Open, 1= Closed
Bit 2
Spare Switch Status
0 = Open, 1= Closed
Bit 3
Differential Switch Status
0 = Open, 1= Closed
Bit 4
Emergency Switch status
0 = Open, 1= Closed
Bit 5
Reset Switch Status
0 = Open, 1= Closed
Bit 6 Reserved
Bit 7 Reserved
F174 Output relay status: unsigned 8 bit integer
