GE 369

CG36 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
DEVICENET PROTOCOL CGCOMMUNICATIONS GUIDE
Bit 0
Trip Relay Status
0 = De-energized, 1 = Energized
Bit 1
Alarm Relay Status
0 = De-energized, 1 = Energized
Bit 2
Aux1 Relay Status
0 = De-energized, 1 = Energized
Bit 3
Aux2 Relay Status
0 = De-energized, 1 = Energized
Bits 4 to 7 Reserved
F175 Flag change state: unsigned 8 bit integer
Bit 0 Trip/Alarm status; 1= operated
Bits 1 to 7 Reserved
F176 Relay trips: bitmask
Byte 1 Bit 0 Single Phasing Trip
Bit 1 Spare Switch Trip
Bit 2 Emergency Switch Trip
Bit 3 Differential Switch Trip
Bit 4 Speed Switch Trip
Bit 5 Reset Switch Trip
Bit 6 Reserved
Bit 7 Overload Trip
Byte 2 Bit 0 Short Circuit Trip
Bit 1 Short Circuit Backup Trip
Bit 2 Mechanical Jam Trip
Bit 3 Undercurrent Trip
Bit 4 Current Unbalance Trip
Bit 5 Ground Fault Trip
Bit 6 Ground Fault Backup Trip
Bit 7 Reserved
Byte 3 Bit 0 Acceleration Timer Trip
Bit 1 RTD 1 Trip
Bit 2 RTD 2 Trip
Bit 3 RTD 3 Trip
Bit 4 RTD 4 Trip
Bit 5 RTD 5 Trip
Bit 6 RTD 6 Trip
Bit 7 RTD 7 Trip
Byte 4 Bit 0 RTD 8 Trip
Bit 1 RTD 9 Trip
Bit 2 RTD 10 Trip
Bit 3 RTD 11 Trip
Bit 4 RTD 12 Trip
Bit 5 Undervoltage Trip
Bit 6 Overvoltage Trip
Bit 7 Voltage Phase Reversal Trip
F176
ctd.
Byte 5 Bit 0 Underfrequency Trip
Bit 1 Overfrequency Trip
Bit 2 Lead Power Factor Trip
Bit 3 Lag Power Factor Trip
Bit 4 Positive kvar Trip
Bit 5 Negative kvar Trip
Bit 6 Underpower Trip
Bit 7 Reverse Power Trip
FORMAT VALUE NAME/DESCRIPTION
