GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG55
RRTD 3 ALARM STATUS
0690 RRTD 3 - RTD #1 Alarm Status 0 4 1 - F123 0
0691 RRTD 3 - RTD #2 Alarm Status 0 4 1 - F123 0
0692 RRTD 3 - RTD #3 Alarm Status 0 4 1 - F123 0
0693 RRTD 3 - RTD #4 Alarm Status 0 4 1 - F123 0
0694 RRTD 3 - RTD #5 Alarm Status 0 4 1 - F123 0
0695 RRTD 3 - RTD #6 Alarm Status 0 4 1 - F123 0
0696 RRTD 3 - RTD #7 Alarm Status 0 4 1 - F123 0
0697 RRTD 3 - RTD #8 Alarm Status 0 4 1 - F123 0
0698 RRTD 3 - RTD #9 Alarm Status 0 4 1 - F123 0
0699 RRTD 3 - RTD #10 Alarm Status 0 4 1 - F123 0
069A RRTD 3 - RTD #11 Alarm Status 0 4 1 - F123 0
069B RRTD 3 - RTD #12 Alarm Status 0 4 1 - F123 0
069C RRTD 3 - RTD #1 High Alarm Status 0 4 1 - F123 0
069D RRTD 3 - RTD #2 High Alarm Status 0 4 1 - F123 0
069E RRTD 3 - RTD #3 High Alarm Status 0 4 1 - F123 0
069F RRTD 3 - RTD #4 High Alarm Status 0 4 1 - F123 0
06A0 RRTD 3 - RTD #5 High Alarm Status 0 4 1 - F123 0
06A1 RRTD 3 - RTD #6 High Alarm Status 0 4 1 - F123 0
06A2 RRTD 3 - RTD #7 High Alarm Status 0 4 1 - F123 0
06A3 RRTD 3 - RTD #8 High Alarm Status 0 4 1 - F123 0
06A4 RRTD 3 - RTD #9 High Alarm Status 0 4 1 - F123 0
06A5 RRTD 3 - RTD #10 High Alarm Status 0 4 1 - F123 0
06A6 RRTD 3 - RTD #11 High Alarm Status 0 4 1 - F123 0
06A7 RRTD 3 - RTD #12 High Alarm Status 0 4 1 - F123 0
06A8 RRTD 3 - Broken / Open RTD Alarm Status 0 4 1 - F123 0
06A9 RRTD 3 - Short / Low Temp Alarm Status 0 1 1 - F123 0
06AA RRTD 3 - Digital Input 6 Alarm Status 0 4 1 - F123 0
06AB RRTD 3 - Digital Input 2 Alarm Status 0 4 1 - F123 0
06AC RRTD 3 - Digital Input 5 Alarm Status 0 4 1 - F123 0
06AD RRTD 3 - Digital Input 4 Alarm Status 0 4 1 - F123 0
06AE RRTD 3 - Digital Input 1 Alarm Status 0 4 1 - F123 0
06AF RRTD 3 - Digital Input 3 Alarm Status 0 4 1 - F123 0
RRTD 4 ALARM STATUS
06B0 RRTD 4 - RTD #1 Alarm Status 0 4 1 - F123 0
06B1 RRTD 4 - RTD #2 Alarm Status 0 4 1 - F123 0
06B2 RRTD 4 - RTD #3 Alarm Status 0 4 1 - F123 0
06B3 RRTD 4 - RTD #4 Alarm Status 0 4 1 - F123 0
06B4 RRTD 4 - RTD #5 Alarm Status 0 4 1 - F123 0
06B5 RRTD 4 - RTD #6 Alarm Status 0 4 1 - F123 0
06B6 RRTD 4 - RTD #7 Alarm Status 0 4 1 - F123 0
06B7 RRTD 4 - RTD #8 Alarm Status 0 4 1 - F123 0
06B8 RRTD 4 - RTD #9 Alarm Status 0 4 1 - F123 0
06B9 RRTD 4 - RTD #10 Alarm Status 0 4 1 - F123 0
06BA RRTD 4 - RTD #11 Alarm Status 0 4 1 - F123 0
06BB RRTD 4 - RTD #12 Alarm Status 0 4 1 - F123 0
06BC RRTD 4 - RTD #1 High Alarm Status 0 4 1 - F123 0
06BD RRTD 4 - RTD #2 High Alarm Status 0 4 1 - F123 0
06BE RRTD 4 - RTD #3 High Alarm Status 0 4 1 - F123 0
06BF RRTD 4 - RTD #4 High Alarm Status 0 4 1 - F123 0
06C0 RRTD 4 - RTD #5 High Alarm Status 0 4 1 - F123 0
06C1 RRTD 4 - RTD #6 High Alarm Status 0 4 1 - F123 0
06C2 RRTD 4 - RTD #7 High Alarm Status 0 4 1 - F123 0
06C3 RRTD 4 - RTD #8 High Alarm Status 0 4 1 - F123 0
06C4 RRTD 4 - RTD #9 High Alarm Status 0 4 1 - F123 0
06C5 RRTD 4 - RTD #10 High Alarm Status 0 4 1 - F123 0
06C6 RRTD 4 - RTD #11 High Alarm Status 0 4 1 - F123 0
06C7 RRTD 4 - RTD #12 High Alarm Status 0 4 1 - F123 0
06C8 RRTD 4 - Broken / Open RTD Alarm Status 0 4 1 - F123 0
Table CG–10: MEMORY MAP (Sheet 10 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
