GE 369

CG70 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
UNDERVOLTAGE
1B60 Undervoltage Active If Motor Stopped 0 1 1 - F103 0
1B61 Undervoltage Alarm 0 2 1 - F115 0
1B62 Assign Alarm Relays 0 7 1 - F113 1
1B63 Undervoltage Alarm Pickup 50 99 1 × Rated F3 85
1B64 Starting Undervoltage Alarm Pickup 50 99 1 × Rated F3 85
1B65 Undervoltage Alarm Delay 0 2550 1 0.1s F2 30
1B66 Undervoltage Alarm Events 0 1 1 - F103 0
1B67 Undervoltage Trip 0 2 1 - F115 0
1B68 Undervoltage Trip Relays 0 7 1 - F111 1
1B69 Undervoltage Trip Pickup 50 99 1 × Rated F3 80
1B6A Starting Undervoltage Trip Pickup 50 99 1 × Rated F3 80
1B6B Undervoltage Trip Delay 0 2550 1 0.1s F2 10
... Reserved
OVERVOLTAGE
1B80 Overvoltage Alarm 0 2 1 - F115 0
1B81 Overvoltage Alarm Relays 0 7 1 - F113 1
1B82 Overvoltage Alarm Pickup 101 125 1 x Rated F3 105
1B83 Overvoltage Alarm Delay 0 2550 1 s F2 10
1B84 Overvoltage Alarm Events 0 1 1 - F103 0
1B85 Overvoltage Trip 0 1 1 - F103 0
1B86 Overvoltage Trip Relays 0 7 1 - F111 1
1B87 Overvoltage Trip Pickup 101 125 1 x Rated F3 110
1B88 Overvoltage Trip Delay 0 2550 1 s F2 10
... Reserved
PHASE REVERSAL
1BA0 Phase Reversal Trip 0 2 1 - F115 0
1BA1 Assign Trip Relays 0 7 1 - F111 1
... Reserved - - - - - -
OVERFREQUENCY
1BB0 Block Overfrequency on Start 0 5000 1 s F1 1
1BB1 Overfrequency Alarm 0 2 1 - F115 0
1BB2 Assign Alarm Relays 0 7 1 - F113 1
1BB3 Overfrequency Alarm Level 2000 7000 1 Hz F3 6050
1BB4 Overfrequency Alarm Delay 0 2550 1 s F2 10
1BB5 Overfrequency Alarm Events 0 1 1 - F103 0
1BB6 Overfrequency Trip 0 1 1 - F103 0
1BB7 Assign Trip Relays 0 7 1 - F111 1
1BB8 Overfrequency Trip Level 2000 7000 1 Hz F3 6050
1BB9 Overfrequency Trip Delay 0 2550 1 s F2 10
... Reserved - - - - - -
UNDERFREQUENCY
1BC0 Block Underfrequency on Start 0 5000 1 s F1 1
1BC1 Underfrequency Alarm 0 2 1 - F115 0
1BC2 Assign Alarm Relays 0 7 1 - F113 1
1BC3 Underfrequency Alarm Level 2000 7000 1 Hz F3 5950
1BC4 Underfrequency Alarm Delay 0 2550 1 s F2 10
1BC5 Underfrequency Alarm Events 0 1 1 - F103 0
1BC6 Underfrequency Trip 0 2 1 - F115 0
1BC7 Assign Trip Relays 0 7 1 - F111 1
1BC8 Underfrequency Trip Level 2000 7000 1 Hz F3 5950
1BC9 Underfrequency Trip Delay 0 2550 1 s F2 10
... Reserved
LEAD POWER FACTOR
1BD0 Block Lead Power Factor From Start 0 5000 1 s F1 1
1BD1 Lead Power Factor Alarm 0 2 1 - F115 0
1BD2 Assign Lead Power Factor Alarm Relays 0 7 1 - F113 1
1BD3 Lead Power Factor Alarm Level 5 99 1 - F3 30
1BD4 Lead Power Factor Alarm Delay 1 2550 1 s F2 10
Table CG–10: MEMORY MAP (Sheet 25 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
