369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG49
0281 Local RTD #5 Alarm Status 0 4 1 - F123 0
0282 Local RTD #6 Alarm Status 0 4 1 - F123 0
0283 Local RTD #7 Alarm Status 0 4 1 - F123 0
0284 Local RTD #8 Alarm Status 0 4 1 - F123 0
0285 Local RTD #9 Alarm Status 0 4 1 - F123 0
0286 Local RTD #10 Alarm Status 0 4 1 - F123 0
0287 Local RTD #11 Alarm Status 0 4 1 - F123 0
0288 Local RTD #12 Alarm Status 0 4 1 - F123 0
0289 Local RTD #1 High Alarm Status 0 4 1 - F123 0
028A Local RTD #2 High Alarm Status 0 4 1 - F123 0
028B Local RTD #3 High Alarm Status 0 4 1 - F123 0
028C Local RTD #4 High Alarm Status 0 4 1 - F123 0
028D Local RTD #5 High Alarm Status 0 4 1 - F123 0
028E Local RTD #6 High Alarm Status 0 4 1 - F123 0
028F Local RTD #7 High Alarm Status 0 4 1 - F123 0
0290 Local RTD #8 High Alarm Status 0 4 1 - F123 0
0291 Local RTD #9 High Alarm Status 0 4 1 - F123 0
0292 Local RTD #10 High Alarm Status 0 4 1 - F123 0
0293 Local RTD #11 High Alarm Status 0 4 1 - F123 0
0294 Local RTD #12 High Alarm Status 0 4 1 - F123 0
0295 Broken / Open RTD Alarm Status 0 4 1 - F123
0296 Short / Low Temp Alarm Status 0 1 1 - F123
0297 Reserved
0298 Trip Counter Alarm Status 0 4 1 - F123 0
0299 Starter Failure Alarm 0 4 1 - F123 0
029A Current Demand Alarm Status 0 4 1 - F123 0
029B kW Demand Alarm Status 0 4 1 - F123 0
029C kvar Demand Alarm Status 0 4 1 - F123 0
029D kVA Demand Alarm Status 0 4 1 - F123 0
029E Self Test Alarm 0 4 1 - F123 0
START BLOCK STATUS
02C0 Overload Lockout Timer 0 9999 1 min F1 0
02C1 Start Timer 1 0 60 1 min F1 0
02C2 Start Timer 2 0 60 1 min F1 0
02C3 Start Timer 3 0 60 1 min F1 0
02C4 Start Timer 4 0 60 1 min F1 0
02C5 Start Timer 5 0 60 1 min F1 0
02C6 Time Between Starts Timer 0 500 1 min F1 0
02C7 Restart Block Timer 0 50000 1 s F1 0
02C8 Reserved
02C9 Start Inhibit Timer 0 500 1 min F1 0
02CA Starts Per Hour Lockout Timer 0 60 1 min F1 0
... Reserved
DIGITAL INPUT STATUS
02D0 Access 0 1 1 - F131 0
02D1 Speed 0 1 1 - F131 0
02D2 Spare 0 1 1 - F131 0
02D3 Differential Relay 0 1 1 - F131 0
02D4 Emergency Restart 0 1 1 - F131 0
02D5 Reset 0 1 1 - F131 0
... Reserved
OUTPUT RELAY STATUS
02E0 Trip 0 1 1 N/A F150 0
02E1 Alarm 0 1 1 N/A F150 0
02E2 Aux.1 0 1 1 N/A F150 0
02E3 Aux.2 0 1 1 N/A F150 0
... Reserved
369 DIGITAL INPUT AND OUTPUT RELAY STATUS
02E6 Digital Input and Output Relay Status N/A N/A N/A N/A F192 0
Table CG–10: MEMORY MAP (Sheet 4 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
