GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG65
1667 Mechanical Jam Trip Level 101 600 1 0.01 × FLA F3 150
1668 Mechanical Jam Trip Delay 5 1250 5 s F2 10
... Reserved - - - - - -
UNDERCURRENT
1670 Block Undercurrent from Start 0 15000 1 s F1 0
1671 Undercurrent Alarm 0 2 1 - F115 0
1672 Assign Undercurrent Alarm Relays 0 7 1 - F113 1
1673 Undercurrent Alarm Level 10 99 1 0.01 × FLA F3 70
1674 Undercurrent Alarm Delay 1 255 1 s F1 1
1675 Undercurrent Alarm Events 0 1 1 - F103 0
1676 Undercurrent Trip 0 2 1 - F115 0
1677 Assign Undercurrent Trip Relays 0 7 1 - F111 1
1678 Undercurrent Trip Level 10 99 1 0.01 × FLA F3 70
1679 Undercurrent Trip Delay 1 255 1 s F1 1
... Reserved
CURRENT UNBALANCE
1680 Block Unbalance From Start 0 5000 1 s F1 0
1681 Current Unbalance Alarm 0 2 1 - F115 0
1682 Assign Unbalance Alarm Relays 0 7 1 - F113 1
1683 Unbalance Alarm Level 4 30 1 % F1 15
1684 Unbalance Alarm Delay 1 255 1 s F1 1
1685 Unbalance Alarm Events 0 1 1 - F103 0
1686 Current Unbalance Trip 0 2 1 - F115 0
1687 Assign Unbalance Trip Relays 0 7 1 - F111 1
1688 Unbalance Trip Level 4 30 1 % F1 20
1689 Unbalance Trip Delay 1 255 1 s F1 1
... Reserved
GROUND FAULT
16A1 Ground Fault Alarm 0 2 1 - F115 0
16A2 Assign Ground Fault Alarm Relays 0 7 1 - F113 1
16A3 Ground Fault Alarm Pickup 10 100 1 0.1 × CT F3 10
16A4
GF Alarm Pickup for GE Multilin 50:0.025
CT
25 2500 1 Amps F3 25
16A5 Ground Fault Alarm Delay 0 255.00 0.01 s F3 0
16A6 Ground Fault Alarm Events 0 1 1 - F103 0
16A7 Ground Fault Trip 0 2 1 - F 115 0
16A8 Assign Ground Fault Trip Relays 0 7 1 - F 111 1
16A9 Ground Fault Trip Pickup 10 100 1 0.1 × CT F3 20
16AA GF Trip Pickup for GE Multilin 50:0.025 CT 25 2500 1 0.1 × CT F3 25
16AB Ground Fault Trip Delay 0 255.00 0.01 s F3 0
16AC Ground Fault Trip Backup 0 1 1 - F115 0
16AD Ground Fault Trip Backup Relays 0 3 1 - F119 33
16AE Ground Fault Trip Backup Delay 0.10 255.00 0.01 s F3 0.20
... Reserved
ACCELERATION TRIP
16D0 Acceleration Trip 0 1 1 - F115 0
16D1 Assign Trip Relays 0 7 1 - F111 1
16D2 Acceleration Timer From Start 10 2500 1 1s F1 100
... Reserved - - - - - -
16E0 Enable Single Shot Restart 0 1 1 - F103 0
16E1 Enable Start Inhibit 0 1 1 - F103 0
16E2 Maximum Starts/Hour Permissible 0 5 1 - F1 0
16E3 Time Between Starts 0 500 1 min F1 10
16E4 Restart Block 0 50000 1 s F1 0
16E5 Assign Block Relays 0 7 1 - F111 3
... Reserved
BACKSPIN DETECTION
1780 Enable Back-Spin Start Inhibit 0 1 1 - F103 0
1781 Minimum Permissible Frequency 0 999 1 Hz F3 100
... Reserved
Table CG–10: MEMORY MAP (Sheet 20 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
