GE 369

CG54 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
0657 RRTD 1 - RTD #8 Alarm Status 0 4 1 - F123 0
0658 RRTD 1 - RTD #9 Alarm Status 0 4 1 - F123 0
0659 RRTD 1 - RTD #10 Alarm Status 0 4 1 - F123 0
065A RRTD 1 - RTD #11 Alarm Status 0 4 1 - F123 0
065B RRTD 1 - RTD #12 Alarm Status 0 4 1 - F123 0
065C RRTD 1 - RTD #1 High Alarm Status 0 4 1 - F123 0
065D RRTD 1 - RTD #2 High Alarm Status 0 4 1 - F123 0
065E RRTD 1 - RTD #3 High Alarm Status 0 4 1 - F123 0
065F RRTD 1 - RTD #4 High Alarm Status 0 4 1 - F123 0
0660 RRTD 1 - RTD #5 High Alarm Status 0 4 1 - F123 0
0661 RRTD 1 - RTD #6 High Alarm Status 0 4 1 - F123 0
0662 RRTD 1 - RTD #7 High Alarm Status 0 4 1 - F123 0
0663 RRTD 1 - RTD #8 High Alarm Status 0 4 1 - F123 0
0664 RRTD 1 - RTD #9 High Alarm Status 0 4 1 - F123 0
0665 RRTD 1 - RTD #10 High Alarm Status 0 4 1 - F123 0
0666 RRTD 1 - RTD #11 High Alarm Status 0 4 1 - F123 0
0667 RRTD 1 - RTD #12 High Alarm Status 0 4 1 - F123 0
0668 RRTD 1 - Broken / Open RTD Alarm Status 0 4 1 - F123 0
0669 RRTD 1 - Short / Low Temp Alarm Status 0 1 1 - F123 0
066A RRTD 1 - Digital Input 6 Alarm Status 0 4 1 - F123 0
066B RRTD 1 - Digital Input 2 Alarm Status 0 4 1 - F123 0
066C RRTD 1 - Digital Input 5 Alarm Status 0 4 1 - F123 0
066D RRTD 1 - Digital Input 4 Alarm Status 0 4 1 - F123 0
066E RRTD 1 - Digital Input 1 Alarm Status 0 4 1 - F123 0
066F RRTD 1 - Digital Input 3 Alarm Status 0 4 1 - F123 0
RRTD 2 ALARM STATUS
0670 RRTD 2 - RTD #1 Alarm Status 0 4 1 - F123 0
0671 RRTD 2 - RTD #2 Alarm Status 0 4 1 - F123 0
0672 RRTD 2 - RTD #3 Alarm Status 0 4 1 - F123 0
0673 RRTD 2 - RTD #4 Alarm Status 0 4 1 - F123 0
0674 RRTD 2 - RTD #5 Alarm Status 0 4 1 - F123 0
0675 RRTD 2 - RTD #6 Alarm Status 0 4 1 - F123 0
0676 RRTD 2 - RTD #7 Alarm Status 0 4 1 - F123 0
0677 RRTD 2 - RTD #8 Alarm Status 0 4 1 - F123 0
0678 RRTD 2 - RTD #9 Alarm Status 0 4 1 - F123 0
0679 RRTD 2 - RTD #10 Alarm Status 0 4 1 - F123 0
067A RRTD 2 - RTD #11 Alarm Status 0 4 1 - F123 0
067B RRTD 2 - RTD #12 Alarm Status 0 4 1 - F123 0
067C RRTD 2 - RTD #1 High Alarm Status 0 4 1 - F123 0
067D RRTD 2 - RTD #2 High Alarm Status 0 4 1 - F123 0
067E RRTD 2 - RTD #3 High Alarm Status 0 4 1 - F123 0
067F RRTD 2 - RTD #4 High Alarm Status 0 4 1 - F123 0
0680 RRTD 2 - RTD #5 High Alarm Status 0 4 1 - F123 0
0681 RRTD 2 - RTD #6 High Alarm Status 0 4 1 - F123 0
0682 RRTD 2 - RTD #7 High Alarm Status 0 4 1 - F123 0
0683 RRTD 2 - RTD #8 High Alarm Status 0 4 1 - F123 0
0684 RRTD 2 - RTD #9 High Alarm Status 0 4 1 - F123 0
0685 RRTD 2 - RTD #10 High Alarm Status 0 4 1 - F123 0
0686 RRTD 2 - RTD #11 High Alarm Status 0 4 1 - F123 0
0687 RRTD 2 - RTD #12 High Alarm Status 0 4 1 - F123 0
0688 RRTD 2 - Broken / Open RTD Alarm Status 0 4 1 - F123 0
0689 RRTD 2 - Short / Low Temp Alarm Status 0 1 1 - F123 0
068A RRTD 2 - Digital Input 6 Alarm Status 0 4 1 - F123 0
068B RRTD 2 - Digital Input 2 Alarm Status 0 4 1 - F123 0
068C RRTD 2 - Digital Input 5 Alarm Status 0 4 1 - F123 0
068D RRTD 2 - Digital Input 4 Alarm Status 0 4 1 - F123 0
068E RRTD 2 - Digital Input 1 Alarm Status 0 4 1 - F123 0
068F RRTD 2 - Digital Input 3 Alarm Status 0 4 1 - F123 0
Table CG–10: MEMORY MAP (Sheet 9 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
