GE 369

CG52 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
043C Ground Fault Trips 0 50000 1 - F1 0
043D Acceleration Trips 0 50000 1 - F1 0
... Reserved
043F Undervoltage Trips 0 50000 1 - F1 0
0440 Overvoltage Trips 0 50000 1 - F1 0
0441 Phase Reversal Trips 0 50000 1 - F1 0
0442 Under Frequency Trips 0 50000 1 - F1 0
0443 Over Frequency Trips 0 50000 1 - F1 0
... Reserved
0446 Lead Power Factor Trips 0 50000 1 - F1 0
0447 Lag Power Factor Trips 0 50000 1 - F1 0
0448 Positive Reactive Power Trips 0 50000 1 - F1 0
0449 Negative Reactive Power Trips 0 50000 1 - F1 0
044A Underpower Trips 0 50000 1 - F1 0
044B Reverse Power Trips 0 50000 1 - F1 0
... Reserved
044E Stator RTD Trips 0 50000 1 - F1 0
044F Bearing RTD Trips 0 50000 1 - F1 0
0450 Other RTD Trips 0 50000 1 - F1 0
0451 Ambient RTD Trips 0 50000 1 - F1 0
0452 UVR Undervoltage Trip Counters 0 50000 1 - F1 Read Only
... Reserved
0454 Incomplete Sequence Trips 0 50000 1 - F1 0
... Reserved
0457 Trip Counters Last Cleared N/A N/A N/A N/A F18 N/A
... Reserved
MOTOR STATISTICS
0470 Number of Motor Starts 0 50000 1 - F1 0
0471 Number of Emergency Restarts 0 50000 1 - F1 0
0472 Reserved - - - - - -
0473 Digital Counter 0 65535 1 - F1 0
... Reserved
04A0 Motor Running Hours 0 65535 1 hr. F1 0
... Reserved
PHASORS
0500 Va Angle 0 359 1 degrees F1 0
0501 Vb Angle 0 359 1 degrees F1 0
0502 Vc Angle 0 359 1 degrees F1 0
0503 Ia Angle 0 359 1 degrees F1 0
0504 Ib Angle 0 359 1 degrees F1 0
0505 Ic Angle 0 359 1 degrees F1 0
... Reserved
REMOTE RTD ACTUAL VALUES (ADDRESSES 0600 TO 1FFF)
RRTD 1 TEMPERATURES
0600 RRTD 1 - Hottest Stator Number 0 12 1 - F1 0
0601 RRTD 1 - Hottest Stator Temperature -40 200 1 °C F4 40
0602 RRTD 1 - RTD #1 Temperature -40 200 1 °C F4 40
0603 RRTD 1 - RTD #2 Temperature -40 200 1 °C F4 40
0604 RRTD 1 - RTD #3 Temperature -40 200 1 °C F4 40
0605 RRTD 1 - RTD #4 Temperature -40 200 1 °C F4 40
0606 RRTD 1 - RTD #5 Temperature -40 200 1 °C F4 40
0607 RRTD 1 - RTD #6 Temperature -40 200 1 °C F4 40
0608 RRTD 1 - RTD #7 Temperature -40 200 1 °C F4 40
0609 RRTD 1 - RTD #8 Temperature -40 200 1 °C F4 40
060A RRTD 1 - RTD #9 Temperature -40 200 1 °C F4 40
060B RRTD 1 - RTD #10 Temperature -40 200 1 °C F4 40
060C RRTD 1 - RTD #11 Temperature -40 200 1 °C F4 40
060D RRTD 1 - RTD #12 Temperature -40 200 1 °C F4 40
... Reserved
Table CG–10: MEMORY MAP (Sheet 7 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
