CG124 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
F141
Unsigned 16 bit integer OUTPUT RELAY STATUS
bit 0 Trip
bit 1 Alarm
bit 2 Auxiliary 1
bit 3 Auxiliary 2
F149
Unsigned 16 Bit Integer CHANNEL 3 APPLICATION
0MODBUS
1 Remote RTD
F150
Unsigned 16 Bit Integer OUTPUT RELAY STATUS
0De - Energized
1Energized
F151
Unsigned 16 Bit Integer CHANNEL TYPE
0RS 485
1Fiber Optic
F152
Unsigned 16 Bit Integer NUMBER OF RECORDS
0 1 × 64 cycles
1 2 × 32 cycles
2 4 × 16 cycles
3 8 × 8 cycles
F156
Unsigned 16 Bit Integer REMOTE RTD COMMUNICATION STATUS
0 Remote RTD Module Communication Lost
1 Remote RTD Communication on Line
F157
Unsigned 16 Bit Integer DIFFERENTIAL SWITCH INPUT FUNCTION
0OFF
1 Differential Switch
2 General Switch
3 Digital Counter
4 Waveform Capture
5 DeviceNet Control
6 Reserved
7 Reserved
Table CG–11: Memory Map Data Formats (Sheet 22 of 27)
CODE TYPE DEFINITION
