CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG123
F134
con’t
297 RTD 11 Open Alarm
298 RTD 12 Open Alarm
299 Starter Operation Monitor Alarm
300 Starter Operation Monitor Trip
301 Block Undercurrent/Underpower (37)
302 Unblock Undercurrent/Underpower (37)
303 Block Current Unbalance (46)
304 Unblock Current Unbalance (46)
305 Block Incomplete Sequence (48)
306 Unblock Incomplete Sequence (48)
307 Block Thermal Model (49)
308 Unblock Thermal Model (49)
309 Block Short Circuit and Backup (50)
310 Unblock Short Circuit and Backup (50)
311 Block Overload Alarm (51)
312 Unblock Overload Alarm (51)
313 Block Ground Fault (51G)
314 Unblock Ground Fault (51G)
315 Block Starts Per Hour and Time Between Starts (66)
316 Unblock Starts Per Hour and Time Between Starts (66)
317 Profibus Loss of Communications
318 UVR Trip
319 UVR Undervoltage On
320 UVR Undervoltage Off
321 UVR In Progress On
322 UVR In Progress Off
323 UVR Close On
324 UVR Close Off
325 UVR Imm. Restart On
326 UVR Imm. Restart Off
327 UVR Stop On
328 UVR Stop Off
329 Motor Starting
F138 Reserved Reserved
F139 Reserved Reserved
Table CG–11: Memory Map Data Formats (Sheet 21 of 27)
