369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG89
2704 RRTD 4 - RTD #9 Alarm 0 2 1 - F115 0
2705 RRTD 4 - RTD #9 Alarm Relays 0 7 1 - F113 1
2706 RRTD 4 - RTD #9 Alarm Level 1 200 1 °C F1 130
2707 Record RRTD 4 - RTD #9 Alarms as Events 0 1 1 - F103 0
2708 RRTD 4 - RTD #9 Trip 0 2 1 - F115 0
2709 Enable RRTD 4 - RTD #9 Trip Voting 0 13 1 - F122 1
270A RRTD 4 - RTD #9 Trip Relays 0 7 1 - F111 1
270B RRTD 4 - RTD #9 Trip Level 1 200 1 °C F1 130
270C RRTD 4 - RTD #9 RTD Type 0 3 1 - F120 0
2710 First Character of RRTD 4 - RTD #9 Name 32 127 1 - F1 ’R’
↓↓
2713 8th Character of RRTD 4 - RTD #9 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #10
2720 RRTD 4 - RTD #10 Application 0 4 1 - F121 0
2721 RRTD 4 - RTD #10 High Alarm 0 2 1 - F115 0
2722 RRTD 4 - RTD #10 High Alarm Relays 0 7 1 - F113 2
2723 RRTD 4 - RTD #10 High Alarm Level 1 200 1 °C F1 130
2724 RRTD 4 - RTD #10 Alarm 0 2 1 - F115 0
2725 RRTD 4 - RTD #10 Alarm Relays 0 7 1 - F113 1
2726 RRTD 4 - RTD #10 Alarm Level 1 200 1 °C F1 130
2727
Record RRTD 4 - RTD #10 Alarms as
Events
0 1 1 - F103 0
2728 RRTD 4 - RTD #10 Trip 0 2 1 - F115 0
2729 Enable RRTD 4 - RTD#10 Trip Voting 0 13 1 - F122 1
272A RRTD 4 - RTD #10 Trip Relays 0 7 1 - F111 1
272B RRTD 4 - RTD #10 Trip Level 1 200 1 °C F1 130
272C RRTD 4 - RTD #10 RTD Type 0 3 1 - F120 0
2730 First Character of RRTD 4 - RTD #10 Name 32 127 1 - F1 ’R’
↓↓
2733 8th Character of RRTD 4 - RTD #10 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #11
2740 RRTD 4 - RTD #11 Application 0 4 1 - F121 0
2741 RRTD 4 - RTD #11 High Alarm 0 2 1 - F115 0
2742 RRTD 4 - RTD #11 High Alarm Relays 0 7 1 - F113 2
2743 RRTD 4 - RTD #11 High Alarm Level 1 200 1 °C F1 130
2744 RRTD 4 - RTD #11 Alarm 0 2 1 - F115 0
2745 RRTD 4 - RTD #11 Alarm Relays 0 7 1 - F113 1
2746 RRTD 4 - RTD #11 Alarm Level 1 200 1 °C F1 130
2747
Record RRTD 4 - RTD #11 Alarms as
Events
0 1 1 - F103 0
2748 RRTD 4 - RTD #11 Trip 0 2 1 - F115 0
2749 Enable RRTD 4 - RTD #11 Trip Voting 0 13 1 - F122 1
274A RRTD 4 - RTD #11 Trip Relays 0 7 1 - F111 1
274B RRTD 4 - RTD #11 Trip Level 1 200 1 °C F1 130
274C RRTD 4 - RTD #11 RTD Type 0 3 1 - F120 0
2750 First Character of RRTD 4 - RTD #11 Name 32 127 1 - F1 ’R’
↓↓
2753 8th Character of RRTD 4 - RTD #11 Name 32 127 1 - F1 " "
... Reserved
RRTD 4 – RTD #12
2760 RRTD 4 - RTD #12 Application 0 4 1 - F121 0
2761 RRTD 4 - RTD #12 High Alarm 0 2 1 - F115 0
2762 RRTD 4 - RTD #12 High Alarm Relays 0 7 1 - F113 2
2763 RRTD 4 - RTD #12 High Alarm Level 1 200 1 °C F1 130
2764 RRTD 4 - RTD #12 Alarm 0 2 1 - F115 0
2765 RRTD 4 - RTD #12 Alarm Relays 0 7 1 - F113 1
2766 RRTD 4 - RTD #12 Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 44 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
