GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG77
20CC RRTD 1 - RTD #7 RTD Type 0 3 1 - F120 0
20D0 First Character of RRTD 1 - RTD #7 Name 32 127 1 - F1 ’R’
↓↓
20D3 8th Character of RRTD 1 - RTD #7 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #8
20E0 RRTD 1 - RTD #8 Application 0 4 1 - F121 0
20E1 RRTD 1 - RTD #8 High Alarm 0 2 1 - F115 0
20E2 RRTD 1 - RTD #8 High Alarm Relays 0 7 1 - F113 2
20E3 RRTD 1 - RTD #8 High Alarm Level 1 200 1 °C F1 130
20E4 RRTD 1 - RTD #8 Alarm 0 2 1 - F115 0
20E5 RRTD 1 - RTD #8 Alarm Relays 0 7 1 - F113 1
20E6 RRTD 1 - RTD #8 Alarm Level 1 200 1 °C F1 130
20E7 Record RRTD 1 - RTD #8 Alarms as Events 0 1 1 - F103 0
20E8 RRTD 1 - RTD #8 Trip 0 2 1 - F115 0
20E9 Enable RRTD 1 - RTD #8 Trip Voting 0 13 1 - F122 1
20EA RRTD 1 - RTD #8 Trip Relays 0 7 1 - F111 1
20EB RRTD 1 - RTD #8 Trip Level 1 200 1 °C F1 130
20EC RRTD 1 - RTD #8 RTD Type 0 3 1 - F120 0
20F0 First Character of RRTD 1 - RTD #8 Name 32 127 1 - F1 ’R’
↓↓
20F3 8th Character of RRTD 1 - RTD #8 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #9
2100 RRTD 1 - RTD #9 Application 0 4 1 - F121 0
2101 RRTD 1 - RTD #9 High Alarm 0 2 1 - F115 0
2102 RRTD 1 - RTD #9 High Alarm Relays 0 7 1 - F113 2
2103 RRTD 1 - RTD #9 High Alarm Level 1 200 1 °C F1 130
2104 RRTD 1 - RTD #9 Alarm 0 2 1 - F115 0
2105 RRTD 1 - RTD #9 Alarm Relays 0 7 1 - F113 1
2106 RRTD 1 - RTD #9 Alarm Level 1 200 1 °C F1 130
2107 Record RRTD 1 - RTD #9 Alarms as Events 0 1 1 - F103 0
2108 RRTD 1 - RTD #9 Trip 0 2 1 - F115 0
2109 Enable RRTD 1 - RTD #9 Trip Voting 0 13 1 - F122 1
210A RRTD 1 - RTD #9 Trip Relays 0 7 1 - F111 1
210B RRTD 1 - RTD #9 Trip Level 1 200 1 °C F1 130
210C RRTD 1 - RTD #9 RTD Type 0 3 1 - F120 0
2110 First Character of RRTD 1 - RTD #9 Name 32 127 1 - F1 ’R’
↓↓
2113 8th Character of RRTD 1 - RTD #9 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #10
2120 RRTD 1 - RTD #10 Application 0 4 1 - F121 0
2121 RRTD 1 - RTD #10 High Alarm 0 2 1 - F115 0
2122 RRTD 1 - RTD #10 High Alarm Relays 0 7 1 - F113 2
2123 RRTD 1 - RTD #10 High Alarm Level 1 200 1 °C F1 130
2124 RRTD 1 - RTD #10 Alarm 0 2 1 - F115 0
2125 RRTD 1 - RTD #10 Alarm Relays 0 7 1 - F113 1
2126 RRTD 1 - RTD #10 Alarm Level 1 200 1 °C F1 130
2127
Record RRTD 1 - RTD #10 Alarms as
Events
0 1 1 - F103 0
2128 RRTD 1 - RTD #10 Trip 0 2 1 - F115 0
2129 Enable RRTD 1 - RTD#10 Trip Voting 0 13 1 - F122 1
212A RRTD 1 - RTD #10 Trip Relays 0 7 1 - F111 1
212B RRTD 1 - RTD #10 Trip Level 1 200 1 °C F1 130
212C RRTD 1 - RTD #10 RTD Type 0 3 1 - F120 0
2130 First Character of RRTD 1 - RTD #10 Name 32 127 1 - F1 ’R’
↓↓
2133 8th Character of RRTD 1 - RTD #10 Name 32 127 1 - F1 " "
... Reserved
Table CG–10: MEMORY MAP (Sheet 32 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
