CG48 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
LAST TRIP DATA
0220 Cause of Last Trip 0 276 1 - F134 0
0221 Last Trip Time (2 words) N/A N/A N/A N/A F19 -
0223 Last Trip Date (2 words) N/A N/A N/A N/A F18 -
0225 Last Trip Motor Speed 0 2 1 N/A F186 -
0226 Phase A Pre-Trip Current 0 65535 1 A F1 0
0228 Phase B Pre-Trip Current 0 65535 1 A F1 0
022A Phase C Pre-Trip Current 0 65535 1 A F1 0
022C Motor Load Pre - Trip 0 2000 1 FLA F3 0
022D Current Unbalance Pre - Trip 0 100 1 % F1 0
022E Ground Current Pre - Trip 0 50000 1 A F2 0
... Reserved - - - - - -
0233 Hottest Stator RTD Owner During Trip 0 5 1 N/A F165 0
0234 Hottest Stator RTD During Trip 0 12 1 - F1 0
0235
Pre-Trip Temperature of Hottest Stator
RTD
-40 200 1 °C F4 0
0236 Pre-Trip Voltage Vab 0 65000 1 V F1 0
0237 Pre-Trip Voltage Vbc 0 65000 1 V F1 0
0238 Pre-Trip Voltage Vca 0 65000 1 V F1 0
0239 Pre-Trip Voltage Van 0 65000 1 V F1 0
023A Pre-Trip Voltage Vbn 0 65000 1 V F1 0
023B Pre-Trip Voltage Vcn 0 65000 1 V F1 0
023C Pre-Trip System Frequency 0 12000 1 Hz F3 0
023D Pre-Trip Real Power -32000 32000 1 kW F4 0
023E Pre-Trip Reactive Power -32000 32000 1 kvar F4 0
023F Pre-Trip Apparent Power 0 50000 1 kVA F1 0
0240 Pre-Trip Power Factor -99 100 1 - F21 0
... Reserved - - - - - -
ALARM STATUS
0260
General Spare Switch Alarm Status or
Starter Monitor Alarm/Trip Status
0 4 1 - F123 0
0261
General Emergency Restart Switch Alarm
Status
0 4 1 - F123 0
0262 General Differential Switch Alarm Status 0 4 1 - F123 0
0263 General Speed Switch Alarm Status 0 4 1 - F123 0
0264 General Reset Switch Alarm Status 0 4 1 - F123 0
... Reserved
0267 Thermal Capacity Alarm 0 4 1 - F123 0
0268 Overload Alarm Status 0 4 1 - F123 0
0269 Mechanical Jam Alarm Status 0 4 1 - F123 0
026A Undercurrent Alarm Status 0 4 1 - F123 0
026B Current Unbalance Alarm Status 0 4 1 - F123 0
026C Ground Fault Alarm Status 0 4 1 - F123 0
... Reserved
026F Undervoltage Alarm Status 0 4 1 - F123 0
0270 Overvoltage Alarm Status 0 4 1 - F123 0
0271 Overfrequency Alarm Status 0 4 1 - F123 0
0272 Underfrequency Alarm Status 0 4 1 - F123 0
... Reserved
0275 Lead Power Factor Alarm Status 0 4 1 - F123 0
0276 Lag Power Factor Alarm Status 0 4 1 - F123 0
0277 Positive kvar Alarm Status 0 4 1 - F123 0
0278 Negative kvar Alarm Status 0 4 1 - F123 0
0279 Underpower Alarm Status 0 4 1 - F123 0
027A Reverse Power Alarm Status 0 4 1 - F123 0
... Reserved
027D Local RTD #1 Alarm Status 0 4 1 - F123 0
027E Local RTD #2 Alarm Status 0 4 1 - F123 0
027F Local RTD #3 Alarm Status 0 4 1 - F123 0
0280 Local RTD #4 Alarm Status 0 4 1 - F123 0
Table CG–10: MEMORY MAP (Sheet 3 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
