GE 369

CG56 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
06C9 RRTD 4 - Short / Low Temp Alarm Status 0 1 1 - F123 0
06CA RRTD 4 - Digital Input 6 Alarm Status 0 4 1 - F123 0
06CB RRTD 4 - Digital Input 2 Alarm Status 0 4 1 - F123 0
06CC RRTD 4 - Digital Input 5 Alarm Status 0 4 1 - F123 0
06CD RRTD 4 - Digital Input 4 Alarm Status 0 4 1 - F123 0
06CE RRTD 4 - Digital Input 1 Alarm Status 0 4 1 - F123 0
06CF RRTD 4 - Digital Input 3 Alarm Status 0 4 1 - F123 0
RRTD 1 MAXIMUM TEMPERATURES
0700 RRTD 1 - RTD # 1 Max. Temperature -40 200 1 °C F4 40
0701 RRTD 1 - RTD # 2 Max. Temperature -40 200 1 °C F4 40
0702 RRTD 1 - RTD # 3 Max. Temperature -40 200 1 °C F4 40
0703 RRTD 1 - RTD # 4 Max. Temperature -40 200 1 °C F4 40
0704 RRTD 1 - RTD # 5 Max. Temperature -40 200 1 °C F4 40
0705 RRTD 1 - RTD # 6 Max. Temperature -40 200 1 °C F4 40
0706 RRTD 1 - RTD # 7 Max. Temperature -40 200 1 °C F4 40
0707 RRTD 1 - RTD # 8 Max. Temperature -40 200 1 °C F4 40
0708 RRTD 1 - RTD # 9 Max. Temperature -40 200 1 °C F4 40
0709 RRTD 1 - RTD # 10 Max. Temperature -40 200 1 °C F4 40
070A RRTD 1 - RTD # 11 Max. Temperature -40 200 1 °C F4 40
070B RRTD 1 - RTD # 12 Max. Temperature -40 200 1 °C F4 40
... Reserved
RRTD 2 MAXIMUM TEMPERATURES
0710 RRTD 2 - RTD # 1 Max. Temperature -40 200 1 °C F4 40
0711 RRTD 2 - RTD # 2 Max. Temperature -40 200 1 °C F4 40
0712 RRTD 2 - RTD # 3 Max. Temperature -40 200 1 °C F4 40
0713 RRTD 2 - RTD # 4 Max. Temperature -40 200 1 °C F4 40
0714 RRTD 2 - RTD # 5 Max. Temperature -40 200 1 °C F4 40
0715 RRTD 2 - RTD # 6 Max. Temperature -40 200 1 °C F4 40
0716 RRTD 2 - RTD # 7 Max. Temperature -40 200 1 °C F4 40
0717 RRTD 2 - RTD # 8 Max. Temperature -40 200 1 °C F4 40
0718 RRTD 2 - RTD # 9 Max. Temperature -40 200 1 °C F4 40
0719 RRTD 2 - RTD # 10 Max. Temperature -40 200 1 °C F4 40
071A RRTD 2 - RTD # 11 Max. Temperature -40 200 1 °C F4 40
071B RRTD 2 - RTD # 12 Max. Temperature -40 200 1 °C F4 40
... Reserved
RRTD 3 MAXIMUM TEMPERATURES
0720 RRTD 3 - RTD # 1 Max. Temperature -40 200 1 °C F4 40
0721 RRTD 3 - RTD # 2 Max. Temperature -40 200 1 °C F4 40
0722 RRTD 3 - RTD # 3 Max. Temperature -40 200 1 °C F4 40
0723 RRTD 3 - RTD # 4 Max. Temperature -40 200 1 °C F4 40
0724 RRTD 3 - RTD # 5 Max. Temperature -40 200 1 °C F4 40
0725 RRTD 3 - RTD # 6 Max. Temperature -40 200 1 °C F4 40
0726 RRTD 3 - RTD # 7 Max. Temperature -40 200 1 °C F4 40
0727 RRTD 3 - RTD # 8 Max. Temperature -40 200 1 °C F4 40
0728 RRTD 3 - RTD # 9 Max. Temperature -40 200 1 °C F4 40
0729 RRTD 3 - RTD # 10 Max. Temperature -40 200 1 °C F4 40
072A RRTD 3 - RTD # 11 Max. Temperature -40 200 1 °C F4 40
072B RRTD 3 - RTD # 12 Max. Temperature -40 200 1 °C F4 40
... Reserved
RRTD 4 MAXIMUM TEMPERATURES
0730 RRTD 4 - RTD # 1 Max. Temperature -40 200 1 °C F4 40
0731 RRTD 4 - RTD # 2 Max. Temperature -40 200 1 °C F4 40
0732 RRTD 4 - RTD # 3 Max. Temperature -40 200 1 °C F4 40
0733 RRTD 4 - RTD # 4 Max. Temperature -40 200 1 °C F4 40
0734 RRTD 4 - RTD # 5 Max. Temperature -40 200 1 °C F4 40
0735 RRTD 4 - RTD # 6 Max. Temperature -40 200 1 °C F4 40
0736 RRTD 4 - RTD # 7 Max. Temperature -40 200 1 °C F4 40
0737 RRTD 4 - RTD # 8 Max. Temperature -40 200 1 °C F4 40
0738 RRTD 4 - RTD # 9 Max. Temperature -40 200 1 °C F4 40
Table CG–10: MEMORY MAP (Sheet 11 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
