GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG75
2004 RRTD 1 - RTD #1 Alarm 0 2 1 - F115 0
2005 RRTD 1 - RTD #1 Alarm Relays 0 7 1 - F113 1
2006 RRTD 1 - RTD #1 Alarm Level 1 200 1 °C F1 130
2007 Record RRTD 1 - RTD #1 Alarms as Events 0 1 1 - F103 0
2008 RRTD 1 - RTD #1 Trip 0 2 1 - F115 0
2009 Enable RRTD 1 - RTD #1 Trip Voting 0 13 1 - F122 1
200A RRTD 1 - RTD #1 Trip Relays 0 7 1 - F111 1
200B RRTD 1 - RTD #1 Trip Level 1 200 1 °C F1 130
200C RRTD 1 - RTD #1 RTD Type 0 3 1 - F120 0
... Reserved
2010 First Character of RRTD 1 - RTD #1 Name 32 127 1 - F1 ’R’
↓↓
2013 8th Character of RRTD 1 - RTD #1 Name 32 127 1 - F1 " "
2014 Reserved
RRTD 1 – RTD #2
2020 RRTD 1 - RTD #2 Application 0 4 1 - F121 0
2021 RRTD 1 - RTD #2 High Alarm 0 2 1 - F115 0
2022 RRTD 1 - RTD #2 High Alarm Relays 0 7 1 - F113 2
2023 RRTD 1 - RTD #2 High Alarm Level 1 200 1 °C F1 130
2024 RRTD 1 - RTD #2 Alarm 0 2 1 - F115 0
2025 RRTD 1 - RTD #2 Alarm Relays 0 7 1 - F113 1
2026 RRTD 1 - RTD #2 Alarm Level 1 200 1 °C F1 130
2027 Record RRTD 1 - RTD #2 Alarms as Events 0 1 1 - F103 0
2028 RRTD 1 - RTD #2 Trip 0 2 1 - F115 0
2029 Enable A Remote RTD #2 Trip Voting 0 13 1 - F122 1
202A RRTD 1 - RTD #2 Trip Relays 0 7 1 - F111 1
202B RRTD 1 - RTD #2 Trip Level 1 200 1 °C F1 130
202C RRTD 1 - RTD #2 RTD Type 0 3 1 - F120 0
... Reserved
2030 First Character of RRTD 1 - RTD #2 Name 32 127 1 - F1 ’R’
↓↓
2033 8th Character of RRTD 1 - RTD #2 Name 32 127 1 - F1 " "
2034 Reserved
RRTD 1 – RTD #3
2040 RRTD 1 - RTD #3 Application 0 4 1 - F121 0
2041 RRTD 1 - RTD #3 High Alarm 0 2 1 - F115 0
2042 RRTD 1 - RTD #3 High Alarm Relays 0 7 1 - F113 2
2043 RRTD 1 - RTD #3 High Alarm Level 1 200 1 °C F1 130
2044 RRTD 1 - RTD #3 Alarm 0 2 1 - F115 0
2045 RRTD 1 - RTD #3 Alarm Relays 0 7 1 - F113 1
2046 RRTD 1 - RTD #3 Alarm Level 1 200 1 °C F1 130
2047 Record RRTD 1 - RTD #3 Alarms as Events 0 1 1 - F103 0
2048 RRTD 1 - RTD #3 Trip 0 2 1 - F115 0
2049 Enable RRTD 1 - RTD #3 Trip Voting 0 13 1 - F122 1
204A RRTD 1 - RTD #3 Trip Relays 0 7 1 - F111 1
204B RRTD 1 - RTD #3 Trip Level 1 200 1 °C F1 130
204C RRTD 1 - RTD #3 RTD Type 0 3 1 - F120 0
2050 First Character of RRTD 1 - RTD # Name 32 127 1 - F1 ’R’
↓↓
2053 8th Character of RRTD 1 - RTD #3 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #4
2060 RRTD 1 - RTD #4 Application 0 4 1 - F121 0
2061 RRTD 1 - RTD #4 High Alarm 0 2 1 - F115 0
2062 RRTD 1 - RTD #4 High Alarm Relays 0 7 1 - F113 2
2063 RRTD 1 - RTD #4 High Alarm Level 1 200 1 °C F1 130
2064 RRTD 1 - RTD #4 Alarm 0 2 1 - F115 0
2065 RRTD 1 - RTD #4 Alarm Relays 0 7 1 - F113 1
2066 RRTD 1 - RTD #4 Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 30 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
