GE 369

CG76 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
2067 Record RRTD 1 - RTD #4 Alarms as Events 0 1 1 - F103 0
2068 RRTD 1 - RTD #4 Trip 0 2 1 - F115 0
2069 Enable RRTD 1 - RTD #4 Trip Voting 0 13 1 - F122 1
206A RRTD 1 - RTD #4 Trip Relays 0 7 1 - F111 1
206B RRTD 1 - RTD #4 Trip Level 1 200 1 °C F1 130
206C RRTD 1 - RTD #4 RTD Type 0 3 1 - F120 0
2070 First Character of RRTD 1 - RTD #4 Name 32 127 1 - F1 ’R’
↓↓
2073 8th Character of RRTD 1 - RTD #4 Name 32 127 1 - F1 " "
2074 Reserved
RRTD 1 – RTD #5
2080 RRTD 1 - RTD #5 Application 0 4 1 - F121 0
2081 RRTD 1 - RTD #5 High Alarm 0 2 1 - F115 0
2082 RRTD 1 - RTD #5 High Alarm Relays 0 7 1 - F113 2
2083 RRTD 1 - RTD #5 High Alarm Level 1 200 1 °C F1 130
2084 RRTD 1 - RTD #5 Alarm 0 2 1 - F115 0
2085 RRTD 1 - RTD #5 Alarm Relays 0 7 1 - F113 1
2086 RRTD 1 - RTD #5 Alarm Level 1 200 1 °C F1 130
2087 Record RRTD 1 - RTD #5 Alarms as Events 0 1 1 - F103 0
2088 RRTD 1 - RTD #5 Trip 0 2 1 - F115 0
2089 Enable RRTD 1 - RTD #5 Trip Voting 0 13 1 - F122 1
208A RRTD 1 - RTD #5 Trip Relays 0 7 1 - F111 1
208B RRTD 1 - RTD #5 Trip Level 1 200 1 °C F1 130
208C RRTD 1 - RTD #5 RTD Type 0 3 1 - F120 0
2090 First Character of RRTD 1 - RTD #5 Name 32 127 1 - F1 ’R’
↓↓
2093 8th Character of RRTD 1 - RTD #5 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #6
20A0 RRTD 1 - RTD #6 Application 0 4 1 - F121 0
20A1 RRTD 1 - RTD #6 High Alarm 0 2 1 - F115 0
20A2 RRTD 1 - RTD #6 High Alarm Relays 0 7 1 - F113 1
20A3 RRTD 1 - RTD #6 High Alarm Level 1 200 1 °C F1 130
20A4 RRTD 1 - RTD #6 Alarm 0 2 1 - F115 0
20A5 RRTD 1 - RTD #6 Alarm Relays 0 7 1 - F113 1
20A6 RRTD 1 - RTD #6 Alarm Level 1 200 1 °C F1 130
20A7 Record RRTD 1 - RTD #6 Alarms as Events 0 1 1 - F103 0
20A8 RRTD 1 - RTD #6 Trip 0 2 1 - F115 0
20A9 Enable RRTD 1 - RTD #6 Trip Voting 0 13 1 - F122 1
20AA RRTD 1 - RTD #6 Trip Relays 0 7 1 - F111 1
20AB RRTD 1 - RTD #6 Trip Level 1 200 1 °C F1 130
20AC RRTD 1 - RTD #6 RTD Type 0 3 1 - F120 0
20B0 First Character of RRTD 1 - RTD #6 Name 32 127 1 - F1 ’R’
↓↓
20B3 8th Character of RRTD 1 - RTD #6 Name 32 127 1 - F1 " "
... Reserved
RRTD 1 – RTD #7
20C0 RRTD 1 - RTD #7 Application 0 4 1 - F121 0
20C1 RRTD 1 - RTD #7 High Alarm 0 2 1 - F115 0
20C2 RRTD 1 - RTD #7 High Alarm Relays 0 7 1 - F113 2
20C3 RRTD 1 - RTD #7 High Alarm Level 1 200 1 °C F1 130
20C4 RRTD 1 - RTD #7 Alarm 0 2 1 - F115 0
20C5 RRTD 1 - RTD #7 Alarm Relays 0 7 1 - F113 1
20C6 RRTD 1 - RTD #7 Alarm Level 1 200 1 °C F1 130
20C7 Record RRTD 1 - RTD #7 Alarms as Events 0 1 1 - F103 0
20C8 RRTD 1 - RTD #7 Trip 0 2 1 - F115 0
20C9 Enable RRTD 1 - RTD #7 Trip Voting 0 13 1 - F122 1
20CA RRTD 1 - RTD #7 Trip Relays 0 7 1 - F111 1
20CB RRTD 1 - RTD #7 Trip Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 31 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
