CG34 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
DEVICENET PROTOCOL CGCOMMUNICATIONS GUIDE
97,98 (low, high) Current demand 16 bits UINT A
99,100 (low, high) Real power demand 16 bits UINT kW
101,102 (low, high) Reactive power demand 16 bits F4 kvar
103, 104 (low, high) Apparent power demand 16 bits UINT kVA
105, 106 (low, high) Peak current demand 16 bits UINT A
107, 108 (low, high) Peak real power demand 16 bits UINT kW
109, 110 (low, high)
Peak reactive power
demand
16 bits F4 kvar
111,112 (low, high)
Peak apparent power
demand
16 bits UINT kVA
113,114 (low, high) Learned acceleration time 16 bits F2 × 0.1 seconds
115,116 (low, high) Learned starting current 16 bits UINT A
117,118 (low, high) Learned starting capacity 16 bits UINT %
1Dh
ACTUAL VALUES
continued
119,120 (low, high)
Learned running cool time
constant
16 bits UINT minutes
121,122 (low, high)
Learned stopped cool time
constant
16 bits UINT minutes
123,124 (low, high) Last starting capacity 16 bits UINT %
125,126 (low, high)
Learned unbalance k-
factor
16 bits UINT --
127,128 (low, high) Number of starts 16 bits UINT --
129,130 (low, high) Number of restarts 16 bits UINT --
131,132 (low, high) Digital counter 16 bits UINT --
133,134 (low, high) Motor running Hours 16 bits UINT hours
135,136 (low, high) Cause of last trip 16 bits F134 --
137 to 140 (low, high) Last trip date 32 bits F18 --
141 to 144 (low, high) Last trip time 32 bits F19 --
145, 146 (low, high) Last pre-trip Ia 16 bits UINT A
147, 148 (low, high) Last pre-trip Ib 16 bits UINT A
149, 150 (low, high) Last Pre-trip Ic 16 bits UINT A
151, 152 (low, high) Last Pre-trip Ig 16 bits F2 × 0.1 A
153, 154 (low, high) Last pre-trip motor load 16 bits F3 × 0.01 FLA
155, 156 (low, high) Last pre-trip unbalance 16 bits UINT %
157, 158 (low, high)
Last pre-trip local hottest
stator RTD
16 bits UINT ---
159, 160 (low, high)
Last pre-trip local hottest
stator RTD temperature
16 bits F4 °C
161, 162 (low, high) Last pre-trip Vab 16 bits UINT volts
163, 164 (low, high) Last pre-trip Vbc 16 bits UINT volts
165, 166 (low, high) Last pre-trip Vca 16 bits UINT volts
167, 168 (low, high) Last pre-trip Van 16 bits UINT volts
1Dh
ACTUAL VALUES
continued
169, 170 (low, high) Last pre-trip Vbn 16 bits UINT volts
171, 172 (low, high) Last pre-trip Vcn 16 bits UINT volts
173, 174 (low, high) Last pre-trip frequency 16 bits F3 × 0.01 Hz
175, 176 (low, high) Last pre-trip kilowatts 16 bits F4 kW
177, 178 (low, high) Last pre-trip kvar 16 bits F4 kvar
179, 180 (low, high) Last pre-trip KVA 16 bits UINT kVA
181, 182 (low, high) Last pre-trip power factor 16 bits F21 × 0.01 PF
183 to 188 Trip diagnostic data 48 bits F176
189 to 196 Alarm diagnostic data 64 bits F177
197, 198 (low, high) Overload lockout timer 16 bits UINT minutes
199, 200 (low, high) Starts timer [1] 16 bits UINT minutes
DATA FORMATS FOR CLASS CODE B0H, INSTANCE 1 (Sheet 5 of 6)
ATTRIBUTE BYTES DESCRIPTION LENGTH FORMAT VALUE/UNIT
