GE 369

CGCOMMUNICATIONS GUIDE MEMORY MAP
369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE CG67
LOCAL RTD #4
17F0 Local RTD #4 Application 0 4 1 - F121 0
17F1 Local RTD #4 High Alarm 0 2 1 - F115 0
17F2 Local RTD #4 High Alarm Relays 0 7 1 - F113 2
17F3 Local RTD #4 High Alarm Level 1 200 1 °C F1 130
17F4 Local RTD #4 Alarm 0 2 1 - F115 0
17F5 Local RTD #4 Alarm Relays 0 7 1 - F113 1
17F6 Local RTD #4 Alarm Level 1 200 1 °C F1 130
17F7 Enable RTD #4 Alarms as Events 0 1 1 - F103 0
17F8 Local RTD #4 Trip 0 2 1 - F115 0
17F9 Enable RTD #4 Trip Voting 0 13 1 - F122 1
17FA Local RTD #4 Trip Relays 0 7 1 - F111 1
17FB Local RTD #4 Trip Level 1 200 1 °C F1 130
17FC Local RTD #4 RTD Type 0 3 1 - F120 0
1800 First Character of Local RTD #4 Name 32 127 1 - F1 ’R’
↓↓
1803 8th Character of Local RTD #4 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #5
1810 Local RTD #5 Application 0 4 1 - F121 0
1811 Local RTD #5 High Alarm 0 2 1 - F115 0
1812 Local RTD #5 High Alarm Relays 0 7 1 - F113 1
1813 Local RTD #5 High Alarm Level 1 250 1 °C / °F F1 130
1814 Local RTD #5 Alarm 0 2 1 - F115 0
1815 Local RTD #5 Alarm Relays 0 7 1 - F113 1
1816 Local RTD #5 Alarm Level 1 200 1 °C F1 130
1817 Record RTD #5 Alarms as Events 0 1 1 - F103 0
1818 Local RTD #5 Trip 0 2 1 - F115 0
1819 Enable RTD #5 Trip Voting 0 13 1 - F122 1
181A Local RTD #5 Trip Relays 0 7 1 - F111 1
181B Local RTD #5 Trip Level 1 200 1 °C F1 130
181C Local RTD #5 RTD Type 0 3 1 - F120 0
1820 First Character of Local RTD #5 Name 32 127 1 - F1 ’R’
↓↓
1823 8th Character of Local RTD #5 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #6
1830 Local RTD #6 Application 0 4 1 - F121 0
1831 Local RTD #6 High Alarm 0 2 1 - F115 0
1832 Local RTD #6 High Alarm Relays 0 7 1 - F113 2
1833 Local RTD #6 High Alarm Level 1 200 1 °C F1 130
1834 Local RTD #6 Alarm 0 2 1 - F115 0
1835 Local RTD #6 Alarm Relays 0 7 1 - F113 1
1836 Local RTD #6 Alarm Level 1 200 1 °C F1 130
1837 Record RTD #6 Alarms as Events 0 1 1 - F103 0
1838 Local RTD #6 Trip 0 2 1 - F115 0
1839 Enable RTD #6 Trip Voting 0 13 1 - F122 1
183A Local RTD #6 Trip Relays 0 7 1 - F111 1
183B Local RTD #6 Trip Level 1 200 1 °C F1 130
183C Local RTD #6 RTD Type 0 3 1 - F120 0
1840 First Character of Local RTD #6 Name 32 127 1 - F1 ’R’
↓↓
1843 8th Character of Local RTD #6 Name 32 127 1 - F1 " "
... Reserved
LOCAL RTD #7
1850 Local RTD #7 Application 0 4 1 - F121 0
1851 Local RTD #7 High Alarm 0 2 1 - F115 0
1852 Local RTD #7 High Alarm Relays 0 7 1 - F113 2
1853 Local RTD #7 High Alarm Level 1 200 1 °C F1 130
Table CG–10: MEMORY MAP (Sheet 22 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
