CG68 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CGCOMMUNICATIONS GUIDE
1854 Local RTD #7 Alarm 0 2 1 - F115 0
1855 Local RTD #7 Alarm Relays 0 7 1 - F113 1
1856 Local RTD #7 Alarm Level 1 200 1 °C F1 130
1857 Record RTD #7 Alarms as Events 0 1 1 - F103 0
1858 Local RTD #7 Trip 0 2 1 - F115 0
1859 Enable RTD #7 Trip Voting 0 13 1 - F122 1
185A Local RTD #7 Trip Relays 0 7 1 - F111 1
185B Local RTD #7 Trip Level 1 200 1 °C F1 130
185C Local RTD #7 RTD Type 0 3 1 - F120 0
1860 First Character of Local RTD #7 Name 32 127 1 - F1 ’R’
↓↓
1863 8th Character of Local RTD #7 Name 32 127 1 - F1 " "
1864 Reserved
LOCAL RTD #8
1870 Local RTD #8 Application 0 4 1 - F121 0
1871 Local RTD #8 High Alarm 0 2 1 - F115 0
1872 Local RTD #8 High Alarm Relays 0 7 1 - F113 2
1873 Local RTD #8 High Alarm Level 1 200 1 °C F1 130
1874 Local RTD #8 Alarm 0 2 1 - F115 0
1875 Local RTD #8 Alarm Relays 0 7 1 - F113 1
1876 Local RTD #8 Alarm Level 1 200 1 °C F1 130
1877 Record RTD #8 Alarms as Events 0 1 1 - F103 0
1878 Local RTD #8 Trip 0 2 1 - F115 0
1879 Enable RTD #8 Trip Voting 0 13 1 - F122 1
187A Local RTD #8 Trip Relays 0 7 1 - F111 1
187B Local RTD #8 Trip Level 1 200 1 °C F1 130
187C Local RTD #8 RTD Type 0 3 1 - F120 0
1880 First Character of Local RTD #8 Name 32 127 1 - F1 ’R’
↓↓
1883 8th Character of Local RTD #8 Name 32 127 1 - F1 " "
1884 Reserved
LOCAL RTD #9
1890 Local RTD #9 Application 0 4 1 - F121 0
1891 Local RTD #9 High Alarm 0 2 1 - F115 0
1892 Local RTD #9 High Alarm Relays 0 7 1 - F113 2
1893 Local RTD #9 High Alarm Level 1 200 1 °C F1 130
1894 Local RTD #9 Alarm 0 2 1 - F115 0
1895 Local RTD #9 Alarm Relays 0 7 1 - F113 1
1896 Local RTD #9 Alarm Level 1 200 1 °C F1 130
1897 Record RTD #9 Alarms as Events 0 1 1 - F103 0
1898 Local RTD #9 Trip 0 2 1 - F115 0
1899 Enable RTD #9 Trip Voting 0 13 1 - F122 1
189A Local RTD #9 Trip Relays 0 7 1 - F111 1
189B Local RTD #9 Trip Level 1 200 1 °C F1 130
189C Local RTD #9 RTD Type 0 3 1 - F120 0
18A0 First Character of Local RTD #9 Name 32 127 1 - F1 ’R’
↓↓
18A3 8th Character of Local RTD #9 Name 32 127 1 - F1 " "
18A4 Reserved
LOCAL RTD #10
18B0 Local RTD #10 Application 0 4 1 - F121 0
18B1 Local RTD #10 High Alarm 0 2 1 - F115 0
18B2 Local RTD #10 High Alarm Relays 0 7 1 - F113 2
18B3 Local RTD #10 High Alarm Level 1 200 1 °C F1 130
18B4 Local RTD #10 Alarm 0 2 1 - F115 0
18B5 Local RTD #10 Alarm Relays 0 7 1 - F113 1
18B6 Local RTD #10 Alarm Level 1 200 1 °C F1 130
18B7 Record RTD #10 Alarms as Events 0 1 1 - F103 0
18B8 Local RTD #10 Trip 0 2 1 - F115 0
Table CG–10: MEMORY MAP (Sheet 23 of 57)
ADDR
(hex)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
