CG32 369 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
DEVICENET PROTOCOL CGCOMMUNICATIONS GUIDE
0Fh
LEARNED DATA
1,2 (low, high) Learned acceleration time 16 bits F2 x 0.1 seconds
3,4 (low, high) Learned starting current 16 bits UINT A
5,6 (low, high) Learned starting capacity 16 bits UINT %
7,8 (low, high)
Learned running cool time
constant
16 bits UINT minutes
9,10 (low, high)
Learned stopped cool time
constant
16 bits UINT minutes
11,12 (low, high) Last starting capacity 16 bits UINT %
13,14 (low, high)
Learned unbalance k-
factor
16 bits UINT --
10h
MOTOR
STATISTICS
1,2 (low, high) Number of starts 16 bits UINT --
3,4 (low, high) Number of restarts 16 bits UINT --
5,6 (low, high) Digital counter 16 bits UINT --
7,8 (low, high) Motor running hours 16 bits UINT hours
11h
CAUSE OF LAST
TRIP
1,2 (low, high) Cause of last trip 16 bits F134 --
12h
LAST PRE-TRIP
DATE AND TIME.
1 to 4(low, high) Last trip date 32 bits F18 --
5 to 8(low, high) Last trip time 32 bits F19 --
13h
LAST PRE-TRIP
CURRENTS
1,2 (low, high) Last pre-trip Ia 16 bits UINT A
3,4 (low, high) Last pre-trip Ib 16 bits UINT A
5,6 (low, high) Last pre-trip Ic 16 bits UINT A
7,8 (low, high) Last pre-trip Ig 16 bits F2 0.1 × A
14h
LAST PRE-TRIP
MOTOR LOAD
1,2 (low, high) Last pre-trip motor load 16 bits F3 × 0.01 FLA
3,4 (low, high) Last pre-trip unbalance 16 bits UINT %
15h
PRE-TRIP STATOR
RTD TEMP.
1,2 (low, high)
Local pre-trip hottest
stator RTD
16 bits UINT ---
3,4 (low, high)
Local pre-trip hottest
stator RTD temperature
16 bits F4 °C
16h
LAST PRE-TRIP
LINE VOLTAGES
1,2 (low, high) Last pre-trip Vab 16 bits UINT volts
3,4 (low, high) Last pre-trip Vbc 16 bits UINT volts
5,6 (low, high) Last pre-trip Vca 16 bits UINT volts
17h
LAST PRE-TRIP
PHASE VOLTAGES
1,2 (low, high) Last pre-trip Van 16 bits UINT volts
3,4 (low, high) Last pre-trip Vbn 16 bits UINT volts
5,6 (low, high) Last pre-trip Vcn 16 bits UINT volts
18h
LAST PRE-TRIP
FREQ.
1,2 (low, high) Last pre-trip frequency 16 bits F3 × 0.01 Hz
19h
LAST PRE-TRIP
POWER
1,2 (low, high) Last pre-trip kilowatts 16 bits F4 kW
3,4 (low, high) Last pre-trip kvar 16 bits F4 kvar
5,6 (low, high) Last pre-trip KVA 16 bits UINT kVA
7,8 (low, high) Last pre-trip power factor 16 bits F21 × 0.01 PF
1Ah
TRIP DIAG.
6 bytes Trip diagnostic data 48 bits F176
1Bh
ALARM DIAG.
8 bytes Alarm diagnostic data 64 bits F177
1Ch
START BLOCK
STATUS
1,2 (low, high) Overload lockout timer 16 bits UINT minutes
3,4 (low, high) Starts timer [1] 16 bits UINT minutes
5,6 (low, high) Starts timer [2] 16 bits UINT minutes
7,8 (low, high) Starts timer [3] 16 bits UINT minutes
9,10 (low, high) Starts timer [4] 16 bits UINT minutes
11,12 (low, high) Starts timer [5] 16 bits UINT minutes
13,14 (low, high) Time between starts timer 16 bits UINT minutes
15,16 (low, high) Restart block timer 16 bits UINT seconds
17,16 (low, high) Start inhibit timer 16 bits UINT minutes
DATA FORMATS FOR CLASS CODE B0H, INSTANCE 1 (Sheet 3 of 6)
ATTRIBUTE BYTES DESCRIPTION LENGTH FORMAT VALUE/UNIT
