5.1 Start and log on to UNICORN
UNICORN software
The UNICORN control software is delivered with the system. UNICORN should be installed
on a PC (optional) with Microsoft Windows operating system. Refer to the UNICORN
manuals for software installation instructions.
Starting UNICORN
See Alarms, on page 54 for more information regarding the UNICORN control system,
warnings and alarms.
ActionStep
Switch on the computer.1
Log on to Windows.2
Start UNICORN by double-clicking on the UNICORN icon on
the Windows desktop.
3
When the Logon dialog box appears, select a user from the Users list and
enter the password.
4
If you log on for the very first time, select the user default and enter the
password default.
Click OK.5
In the System Control module, on the System menu, click Connect.6
In the dialog shown, select the appropriate system name and click OK. The
system name is specified during installation configuration.
7
When UNICORN is connected to the system, the Run button in the status
bar is enabled. The button initially has a green color indicating the system
is ready to run.
8
ÄKTA ready Operating Instructions 28960345 AD 75
5 Starting ÄKTA ready
5.1 Start and log on to UNICORN
