4.6 Connections
Connector locations
A cable for system power is permanently mounted on the back of the system cabinet.
Connectors for pressurized air, computer network and customer I/O are are also located
on the back of the system unit, at the bottom of the cabinet. Two computer network
cables, and a connector for the customer I/O are supplied but not mounted. For more
information about connector locations, see Components on system cabinet — back, on
page 40.
Power
WARNING
High voltage. The mains cable must only be connected by autho-
rized service personnel. Faulty connection might result in live system
parts that can give lethal electric shocks.
NOTICE
Do not turn on the Mains power switch before all connections are
made.
Power connection
The mains power supply must be connected and configured by authorized service per-
sonnel. Please contact your GE Healthcare representative.
Compressed air
NOTICE
Check that the Pressure Control Regulator for the system air supply
is set to the pressure stated in the specifications.
ÄKTA ready Operating Instructions 28960345 AD 67
4 Installation
4.6 Connections
