System Overview
Page 2-2
2.1. General Description
Only properly trained persons can operate this equipment.
Brivo OEC 715/785/865 Mobile C-Arm X-Ray Product includes:
• Mobile C-Arm, console, X-Ray generator, X-Ray image intensifier, display device (monitor frame,
monitor, computer and power supply units).
• Hardware Options:
Thermal/Film printer
Laser aimer on the image intensifier
Laser aimer on the tube
30cm skin spacer
Film cassette holder
Video distributor for external DVI video output
Removable filter
Removable grid
Footswitch
DVD Driver
Dual 19” Mono LCD Monitor (only for Brivo OEC 785)
Wi-Fi Internet Adapter (only for Brivo OEC 865)
• Nominal Length of External Cables:
Interconnect cable: 8.0m
Bundle cable: 2.5m
Power cable: 7.5m
Handswitch cable: 0.8m
Footswitch cable: 10m/5m for multifunctional two-pedal footswitch with save button
8m/5m for two-pedal footswitch
Please refer to Chapter 12 “Technical Reference” for more details on some hardware options.
