GE LOGIQ E9 User Guide

Console Overview
LOGIQ E9 – User Guide 1-9
Direction 5454884-100 English Rev. 1
USB Ports
Operator Panel
The two Operator Panel USB Ports SHOULD ONLY BE USED
for Bus-powered USB Hard Disk Drives and USB Flash Drives.
The following configurations can be used:
• One or two USB Flash Drives
• One Flash Drive and One Bus-powered Hard Disk Drive
• One Bus-powered Hard Disk Drive
Below Operator Panel and Rear of System
The two USB ports at the back of the system and the two USB
ports below the Operator Panel SHOULD ONLY BE USED for
the following devices:
• Color or Report Printer
NOTE: When connecting an external printer to the LOGIQ E9 via
the USB port on the back of the system, you MUST ensure
that the power supplied to the printer is fed from the same
power feed as the LOGIQ E9. This assures compliance to
leakage currents.
• Flash Drive
• Service Key
CAUTION
Peripheral devices that use their own AC power source cannot
be attached to the system.
CAUTION
DO NOT plug in TWO Bus-powered Hard Disk Drives at the
same time.
CAUTION
ONLY plug in devices to the USB ports located at the rear of
the system WHILE the LOGIQ E9 is NOT powered up. If you
plug in a device while the LOGIQ E9 is powered on, your
system may become unusable.

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
