Getting Started
1-52
LOGIQ E9
–
User Guide
Direction 5454884-100 English
Rev. 1
Multi Angle Biopsy Guide Assembly (continued)
3. Fit a convex of the biopsy bracket (a) in a concave of the
probe (b).
Figure 1-29. Probe/Bracket Alignment
Hold the side (a) and tuck down the needle guide side (b)
until it clicks or locks in place.
Figure 1-30. Probe/Multi-angle Bracket Alignment 2
4. Place an adequate amount of coupling gel on the face of the
probe.
