DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
8 - 84 Section 8-2 - DISASSEMBLY/RE-ASSEMBLY
8-2-38 ECG Cable Hook
8-2-38-1 Tools
• Common philips screwdrivers
8-2-38-2 Removal procedure
1.) Unscrew 2 screws (1-2) to remove the ECG Cable Hook. Refer to the Figure 8-126.
2.) Perform the following functional tests. If all are successful, include the debrief script provided below.
8-2-38-3 Mounting Procedure
Install the new parts in the reverse order of removal.
Figure 8-126 Cable hook on the bottom of keyboard
Table 8-39 Functional Tests
Service Manual
Section
Functional Test / Diagnostic Test Debrief Script
Section 4-3-1
Power On/Boot Up
“Service Manual, Direction
5245279, Rev 3+, Section 8-2-38. Equipment
passed all required tests and is ready for use. “
Section 4-3-2
Power Off / Shutdown
Section 4-8-1
Cover Parts Function Validation
Section 10-5-5
Physical Inspection
(1)
(2)
To Next Page
