44x/EN ST/Hb6
-68 MiCOM P40 Agile
Menu text Default setting
Setting range
Step size
Min Max
GROUP 1 – AUTORECLOSE
1P Trip Mode 1 1 – Single
1/3 – Single/Three
1/3/3 – Single/Three/Three
1/3/3/3 – Single/Three/Three/Three
Number of shots, single pole trip mode (displayed if “A/R single pole” is enabled (‘CB
Control’ column)).
This setting is enabled if the first fault is a single phase fault. The first shot is a single mode
high speed autoreclose shot and, if the relay has been set to allow more than one reclose,
then the second, third and fourth shots are converted to three-pole time-delayed
autoreclose trips.
3P Trip Mode 1 3 – Three
3/3 – Three/Three
3/3/3 – Three/Three/Three
3/3/3/3 – Three/Three/Three/Three
Number of shots, three-pole trip mode (displayed if “A/R Three pole” is enabled (‘CB
Control’ column)).
This cell sets three-pole autoreclose shots. Up to four three-pole autoreclose shots are
settable (1 high speed and three time-delayed autoreclose shots).
1P - Dead Time 1 1s 0.1s 5s 0.01s
3P - Dead Time 1 1s 0.1s 60s 0.01s
Single-/ Three-pole dead time is displayed if “A/R single / Three pole” is enabled (‘CB
Control’ column).
This setting is enabled if the first fault is a multi phase fault. Dead Times 1 (1P or 3P)
dead time for the first high speed shot of the single pole or three-pole reclosure.
Dead Time 2 60s 1s 3600s 1s
Dead Time 3 180s 1s 3600s 1s
Dead Time 4 180s 1s 3600s 1s
Dead Times for second, 3
rd
and 4
th
shot (when set). The dead times are independently
adjustable. The CB close signal is given at the end of this time-delay.
Reclaim Time 180s 1s 600s 1s
Set the reclaim time. The reclaim time starts when the CB is closed. The reclaim time
should be set according to the fault incidence, the CB spring charging time, the switchgear
maintenance and the tZ2 zone delay.
Reclose Time Delay 0.1s 0.1s 10s 0.1s
Set the time-delay before CB reclosure. The Reclose time-delay maintains the linked
reclose contact closed for a time sufficient to ensure reliable CB mechanism operation
Discrimination Time 5s 0.1s 5s 0.01s
The discrimination time-delay is used to differentiate between an evolving fault from a
second fault in the power system and a long circuit breaker operation.
A/R Inhibit Wind
(CB healthy application)
5s 1s 3600s 1s
The "A/R Inhibit Wind" timer setting can be used to prevent autoreclose being initiated when
the CB is manually closed onto a fault. Autoreclose is disabled for the AR Inhibit Wind
following manual CB Closure.
