Programmable Logi
c
P44x/EN PL/Hb
6
MiCOM 40 Agile P442, P444
(PL) 6-
27
Ordinal English Text Description Source
1063 I>3 Timer Block
Block phase overcurrent stage 3 time delay
Set to 1: 'I>3 Time Delay' will be blocked & I>3 will start
but will not issue any trip command.
Reset to 0: opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) I>3
1064 I>4 Timer Block
Block phase overcurrent stage 4 time delay
Set to 1: 'I>4 Time Delay' will be blocked & I>4 will start
but will not issue any trip command.
Reset to 0: opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) I>4
1065 I2>1 Timer Block Block negative sequence overcurrent stage 1 time delay PSL (IN) I>4
1066 I2>2 Timer Block Block negative sequence overcurrent stage 2 time delay PSL (IN) I>5
1067 I2>3 Timer Block Block negative sequence overcurrent stage 3 time delay PSL (IN) I>6
1068 I2>4 Timer Block Block negative sequence overcurrent stage 4 time delay PSL (IN) I>7
1069 V<1 Timer Block
Block phase undervoltage stage 1 time delay
Set to 1: 'V<1 Time Delay' will be blocked and V<1 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V<1
1070 V<2 Timer Block
Block phase undervoltage stage 2 time delay
Set to 1: 'V<2 Time Delay' will be blocked and V<1 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V<2
1071 V<3 Timer Block
Block phase undervoltage stage 3 time delay
Set to 1: 'V<3 Time Delay' will be blocked and V<1 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V<3
1072 V<4 Timer Block
Block phase undervoltage stage 4 time delay
Set to 1: 'V<4 Time Delay' will be blocked and V<1 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V<4
1073 V>1 Timer Block
Block phase overvoltage stage 1 time delay
Set to 1: 'V>1 Time Delay will be blocked and V>1 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V>1
1074 V>2 Timer Block
Block phase overvoltage stage 2 time delay
Set to 1: 'V>2 Time Delay' will be blocked and V>2 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V>2
1075 V>3 Timer Block
Block phase overvoltage stage 3 time delay
Set to 1: 'V>3 Time Delay' will be blocked and V>3 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V>3
1076 V>4 Timer Block
Block phase overvoltage stage 4 time delay
Set to 1: 'V>4 Time Delay' will be blocked and V>4 will
start but will not issue any trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input OR DDB at 0 if signal assigned to a DDB cell
PSL (IN) V>4
1077 VN>1 Timer Block Block earth overvoltage stage 1 time delay
PSL (IN)
VN>1
1078 VN>2 Timer Block Block earth overvoltage stage 2 time delay
PSL (IN)
VN>2
