GE P444 - Page 348

P
44x/EN PL/Hb6
Programmable Logic
(PL) 6
-28 MiCOM 40 Agile
P442, P444
Ordinal English Text Description Source
1079 DIST. Tim. Block
Block distance element time delay
At 1: The distance timer will be blocked & DIST will start
but will not perform a Trip command.
Reset to 0: Opto input power off if signal assigned to an
opto input
OR DDB at 0 if signal assigned to a DDB cell
PSL (IN)
Distance
1080 Reset Lockout
Reset all CB monitoring lockout (all counters and values
are reset ('CB condition')
PSL (IN) CB
Monitoring
1081 Reset All values
Reset all values of CB monitoring (all counters and
values are reset ('CB condition')
PSL (IN) CB
Monitoring
1082 Reset Latches
Reset all permanent alarms + LEDs and relays are
lached
PSl (IN)
1083 Stub Bus Enable
Enable I>4 Element for stub bus protection (isolator of
HV line open - status isolator must be connected to an
opto input)
PSL (IN)
1084 User Trip A
Internal input for trip logic A
Set to 1: Trip A Internal input managed with the general
trip logic(with A/R / Evolving fault…)
Can be assigned by external condition
PSL (IN) Trip
Logic
1085 User Trip B
Internal input for trip logic B
Set to 1: Trip B Internal input managed with the general
trip logic(with A/R / Evolving fault…)
Can be assigned by external condition
PSL (IN)
Trip Logic
1086 User Trip C
Internal input for trip logic C
Set to 1: Trip C Internal input managed with the general
trip logic(with A/R / Evolving fault…)
Can be assigned by external condition
PSL (IN)
Trip Logic
1087 ZSP Timer Block
Zero Sequence Power - Timer Block: If assigned to an
opto input in a dedicated PSL, Zero Sequence Power
function will start, but will not perform a trip command -
the associated time-delay (adjusted with 'K Time Delay
Factor ' setting, will be blocked
PSL (IN)
ZSP
1088 PAP TeleTrip CR
PAP (specific application) Carrier Receive for
teletransmission
PSL(IN)
1089 PAP TeleT. Heath
PAP (specific application) Carrier Out of Service (DT trip
decision)
PSL(IN)
1090 PAP Timer Block
Timer Block for frosen every timer initiated with PAP
(specific application) function
PSL(IN)
1091 Reset Thermal Reset Thermal Overload Protection PSL(IN)
1092 Time Synch External time synchronisation input PSL(IN)
1093 Select CS(NCIT) Select Check synchro for NCIT PSL
1094 T1 Timer Block Timer block T1 input PSL
1095 T2 Timer Block Timer block T2 input PSL
1096 TZp Timer Block Timer block TZp input PSL
1097 TZq Timer Block Timer block TZq input PSL
1098 T3 Timer Block Timer block T3 input PSL
1099 T4 Timer Block Timer block T4 input PSL
1100 F<1 Timer Block Timer block underfrequency stage 1 PSL (IN)
1101 F<2 Timer Block Timer block underfrequency stage 2 PSL (IN)
1102 F<3 Timer Block Timer block underfrequency stage 3 PSL (IN)
1103 F<4 Timer Block Timer block underfrequency stage 4 PSL (IN)
1104 F>1 Timer Block Timer block overfrequency stage 1 PSL (IN)
1105 F>2 Timer Block Timer block overfrequency stage 2 PSL (IN)
1106 I<1 Block Block phase undercurrent stage 1 PSL (IN)
1107 I<2 Block Block phase undercurrent stage 2 PSL (IN)
1108 I<1 Timer Block Timer block phase undercurrent stage 1 PSL (IN)
