Ordinal English Text Description Source
1109 I<2 Timer Block Timer block phase undercurrent stage 2 PSL (IN)
1110 103 MontorBlock
For IEC-870-5-103 protocol only, used for "Monitor
Blocking" (relay is quiet - issues no messages via
SCADA port)
PSL
1111
103
CommandBlock
For IEC-870-5-103 protocol only, used for "Command
Blocking" (relay ignores SCADA commands)
PSL
1112 RP1 Read Only
All setting changes and most command/control actions
blocked for Rear Port 1.
PSL
1113 RP2 Read Only
All setting changes and most command/control actions
blocked for Rear Port 2.
PSL
1114 NIC Read Only
All setting changes and most command/control actions
blocked for the Ethernet port (when option available).
PSL
1115 SBO InterLock 1
SBO support for IEC 61850-8-1 control function with
interlocking facilities 1
PSL
1116 SBO DPI1 Org1
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 1
PSL
1117 SBO DPI2 Org1
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 1
PSL
1118 SBO Command1 SBO support for IEC 61850-8-1 function command 1 PSL
1119 SBO InterLock 2
SBO support for IEC 61850-8-1 control function with
interlocking facilities 2
PSL
1120 SBO DPI1 Org2
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 2
PSL
1121 SBO DPI2 Org2
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 2
PSL
1122 SBO Command2 SBO support for IEC 61850-8-1 function command 2. PSL
1123 SBO InterLock 3
SBO support for IEC 61850-8-1 control function with
interlocking facilities 3
PSL
1124 SBO DPI1 Org3
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 3
PSL
1125 SBO DPI2 Org3
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 3
PSL
1126 SBO Command3 SBO support for IEC 61850-8-1 function command 3 PSL
1127 SBO InterLock 4
SBO support for IEC 61850-8-1 control function with
interlocking facilities 4
PSL
1128 SBO DPI1 Org4
SBO support for IEC 61850-8-1 function. SBO Double
Point Information 1 Organe 4
PSL
1129 SBO DPI2 Org4
SBO support for IEC 61850-8-1 function SBO Double
Point Information 2 Organe 4
PSL
1130 SBO Command4 SBO support for IEC 61850-8-1 function command 4. PSL
1131 to
1223
-- Unused PSL
1224 Virtual Input 1
Goose input n° 1 - Allows binary signals that are
mapped to virtual inputs to interface into PSL
SW
1225 to
1287
Virtual Input 2 to
Virtual Input 64
Goose input n° 2 to
Goose input n° 32
SW
1288 to
1352
-- Unused PSL
1353 to
1415
Quality VIP 1 to
Quality VIP 64
Validation of the virtual input 1 (to 64)
(signal correct).
PSL
1416 to
1479
-- Unused PSL
1480 to
1543
PubPres VIP 1 to
PubPres VIP 64
Publishing presence of virtual input 1 (to 64): indicates
virtual input 1 (to 64) presence.
PSL
