Ordinal English Text Description Source
1544 to
2047
-- Unused (except next DDBs for specific options) PSL
1672 to
1677
LN1 Analog Alarm
to
LN6 Analog Alarm
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
If two consecutive of any Logical Node frames have not
been received within the Merge Unit Delay set
parameter (time of silence in the reception of the frame),
the LN is “absent”
PSL
1680 to
1685
LN1 Test Mode to
LN6 Test Mode
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
Any Logical Node is in “Test Mode”
PSL
1688 to
1693
LN1 Async to
LN6 Async
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
Any Logical Node is synchronized with Internal (local)
synchronization
PSL
1696 to
1701
LN1 Val Quest to
LN6 Val Quest
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
The sample value (SV) transmitted status from the LN is
“questionable”
PSL
1704 to
1709
LN1 Val Fail to
LN6 Val Fail
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
The sample value (SV) transmitted status from the LN is
“failed”
PSL
1.1.2 Sorted by name
Ordinal
English Text
Description
Source
1111 103 CommandBlock
For IEC-870-5-103 protocol only, used for "Command
Blocking" (relay ignores SCADA commands)
PSL
1110 103 MontorBlock
For IEC-870-5-103 protocol only, used for "Monitor
Blocking" (relay is quiet - issues no messages via
SCADA port)
PSL
328 1P Trip Single pole trip (internal or external)
PSL (OUT)
All protection
318 1ph Fault Single phase fault
PSL (OUT)
Distance
319 2ph Fault Two phase fault
PSL (OUT)
Distance
329 3P Trip Three pole trip (internal or external)
PSL (OUT)
All protection
320 3ph Fault Three phase fault
PSL (OUT)
Distance
224 A/R 1P In Prog
One-pole autoreclose cycle in progress: A single pole
autoreclose cycle is in progress. This output will remain
activated from the initial protection trip until the circuit
breaker is closed successfully or the autoreclose
function is Locked Out, indicating that a dead time
timeout is in progress. This signal may be useful during
relay commissioning to check the operation of the
autoreclose cycle.
PSL (OUT)
Autorecloser
226 A/R 1st In Prog
First high speed autoreclose cycle in progress: Used to
indicate the autorecloser is timing out its first dead
time, either a high-speed single-pole shot or a high
speed three-pole shot.
PSL (OUT)
Autorecloser
