44x/EN PL/Hb6
-36 MiCOM 40 Agile
Ordinal English Text Description Source
1040 CB Healthy
Circuit breaker operational (gas pressure, mechanical
state)
Must be at 1 inside the time window (setting: group1/
Autoreclose mode/ AR Inhibit Wind) during an AR
cycle ('A/R close' and 'A/R Reclaim' pick up when 'CB
healthy' is detected during the 'A/R Inhibit Wind' time-
delay')
PSL (IN) CB
STATUS
185 CB Op Time Lock
CB locked out, due to excessive operating time: An
alarm is issued when the operating tripping time on any
phase pass over the 'CB monitor setup / CB Time
Lockout' setting (slowest pole detection calculated by
I< from CB Fail logic)
PSL (OUT)
CB
monitoring
184 CB Op Time Maint
CB excessive operating time alarm: An alarm is issued
when the operating tripping time on any phase pass
over the 'CB monitor setup / CB Time Maint' setting
(slowest pole detection calculated by I< from CB Fail
logic)
PSL (OUT)
CB
monitoring
183 CB Ops Lockout
Circuit breaker operation number lockout (2
nd
level
alarm): An alarm is issued when the maximum of CB
operations is reached [initiated by internal or external
trip, see setting: ‘CB Monitor Setup\N° CB Ops Lockt.]
Set to 0: Until number of operations is below the ‘N°
CB Ops Lockt.” setting. The DDB:'Reset all values'
resets this counter.
PSL (OUT)
CB
monitoring
182 CB Ops Maint
Circuit breaker operations number alarm (1
st
level): An
alarm is issued when the maximum of CB operations is
reached. This alarm is initiated by internal (any
protection function) or external trip (via opto input). The
Alarm can be set with ‘CB Monitor Setup / N° CB Ops
Maint.’ setting.
Set to 0: Until number of operations is below the ‘N°
CB 0ps Maint.’ setting. The DDB:'Reset all values'
resets this counter.
PSL (OUT)
CB
monitoring
189 CB Status Alam
Circuit Breaker Alarm
Displayed when a CB Failure or CB State unknown
condition is detected (the ‘System data / Plant Status’
two last digits = 00 or 11). The CB discrepancy status
is detected after CBA time-delay issued by opto input
or internally by CBAux logic – Alarm issued after 5 s
PSL (OUT)
236 Check Synch. OK
If linked to an opto input in a dedicated PSL and
energised, it indicates that external synchronism
conditions are met – This can be linked afterwards to
an internal autoreclose logic
PSL (OUT)
Synchro
Check
471 Comm2 H/W FAIL Alarm second rear port PSL(OUT)
336 Control Close
Control close command from user (by internal CB
control)
PSL (OUT)
CB control
608 Control input 1
Control Input 1 - for SCADA and menu commands into
PSL
SW
609 to
639
Control input 2 to
Control input 32
Control input 2 to
Control input 32
SW
193 Control No C/S
Autoreclosed works without check synchronism (high
when the internal Check Synchronism conditions are
not met).
PSL (OUT)
335 Control Trip
Control trip command from user (by internal CB
control)
PSL (OUT)
CB control
201 COS Alarm HF carrier anomaly alarm (Carrier out of service)
PSL(OUT)
Unblocking
logic
346 Cross Count. Flt
Cross Country Fault
Set to 1: The cross country logic is activated (1 Fault
Fwd/1 Fault Rev detected)
PSL (OUT)
Distance
